Double wires cutting peeling machine
- 50 Set / Sets per Month
- ShenZhen
- T/T
Product Details
Place of Origin: | Guangdong, China | Brand Name: | HaiSheng | Model Number: | HS-680-1 |
Usage: | Stripping |
Product Description
Double wires cutting peeling machine
Introduction:
The machine uses the latest 32 intelligent control system, Chinese and English switching liquid crystal display, button operation, can store hundreds of pieces of information, called at any time, fast efficient,Compatible with the general features of 330# wire cutting machine.Double linear,two wires can be processed simultaneously,not only saves labor and time,but also improve productivity.Mainly used for electronic wire, silicone wire,Teflon wire, glass fiber of cotton,isolated lines,coaxial,trunking.Automatic cutting, stripping, semi-stripping,multi-segment stripping , twisting function once completed, can instantly transform wire specifications and dimensions,it’s very economic. The machine is mainly used in electronics, electrical appliances, toys, auto parts and other industries.
Features:
1. Double wires cutting peeling machine, high yield
2. Catheter motor drive is power without noise, two times service life higher than conventional.
3. Adjust the position of the catheter directly up on the screen.
4. The new motherboard upgrade one-third faster than the old
5. Feeding wire wheel spindle increased to 12MM, wire feeding stable and durable, not easily deformed.
6. LCD display, simple and intuitive
Parameters:
Type | HS-680-1 |
Size | 470mm×450×340 |
Weight | 40kg |
Display method | Chinese or English interface display |
Power supply | AC220/50Hz |
Capacity | 420W |
Cutting length | 1mm---99999mm |
Cutting Tolerance | Adjustable |
Peeling length | 1.0mm-999.9mm(According to the wire) |
Applicable wire core area | 32 # -12 # (double wires) single-line maximum to 8 |
Productivity | 3500-7000pcs/h(according to the cutting length)output 2wires once |
Tool Material | Tungsten steel / white steel |
Stripping speed | Fast |
Cable outer diameter | Adjustable |
Stripping quality | Excellent |
Decimal precision | Yes |
Drive mode | Four simultaneously drive |
Stripping pressure adjustment: | Adjustable |
Speed adjustment | 0-9 |
Stripping Mode | long wire/ short wire /Multi-stripping / multi stripping |
Equipment Display:
Packing Method:
FACTORY SHOW:
Warranty:
Under normal operation condition, this contract mechanical is guaranteed by seller for one year non-pay repairmen after the date of shipment. Otherwise, the damages caused for the force majeure or accidents or reasons beyond control, buyer shall pay charges for parts and the parts freight and the technicians. Normalblade wear is not covered under warranty,but we will promise you at least 0.5 million times of cutting per piece of blade.
FAQ
1):Are you HaiSheng Automation Equipment a trader or a factory?
We are a company specializing in the production of Cable Manufacturing Equipment, such as fully automatic terminal crimping machine, automatic wire stripping and cutting machine, automatic winding wire binding machine, automatic nylon tie belt machine, ultra quiet energy-saving terminal crimping machine, coaxial cable stripping machine, full automatic peeling and twisting wire machine and so on.
2)Whether the equipment can be customized?
We could provide you with custom-made equipment, according to the wire diameter, length, and other factors of production
3) Is your price competitive?
We are the equipment manufacturer, not trading company, we will provide you with the best price
4)Where is your factory located? How can I visit there?
Our factory is located in ShenZhen City, Guangdong Province, China. Nearby the ShenZhen BaoAn Airport,welcome to visit our factory. We will pick you up at the airport.
