Silicon Carbide Graphite Crucibles Ceramic Crucible for Melting Aluminum
Name | Alumina Melting Pot Crucible | |
Chemical Ingredient | Al2O3 | >=99.7 |
R2O | <=0.02 | |
Fe2O3 | <=0.01 | |
SiO2 | <=0.2 | |
Volume Density (G/Cm2) | >=3.90 | |
Apparent Porosity (%) | <1 | |
Bending Strength (Mpa) | >350 | |
Compression Strength (Mpa) | >12000 | |
Dielectric Constant∑(Mhz) | 2 | |
Max. Service Temperature (C) | 1800 | |
1. Shapes of crucible for melting aluminium:
- arc alumina/zircoina/silicon carbide pot crucible,
- square alumina/zirconia pot crucible,
- rectangle alumina/zirconia pot crucible,
- ...any other shapes.
All kinds of shaped crucibles can be customized.
2. Standard Sizes of crucible for melting aluminium:
5ml 10ml 15ml 20ml 25ml 30ml 50ml 100ml 150ml 200ml- 2500ml
Capacity (ml) | Specification (mm) |
5 | Dia20x25x2 |
10 | Dia29x33x2.5 |
20 | Dia34x38x2.5 |
30 | Dia38x44x2.5 |
40 | Dia42x45x2.5 |
50 | Dia45x48x2.5 |
60 | Dia47x47x2.5 |
70 | Dia50x55x2.5 |
80 | Dia50x56x2.5 |
100 | Dia52x60x2.5 |
120 | Dia45x120x2.5 |
130 | Dia57x66x2.5 |
150 | Dia50x100x2.5 |
170 | Dia50x120x2.5 |
250 | Dia65x80x3 |
280 | Dia65x105x3 |
300 | Dia85x60x3 |
320 | Dia70x100x3 |
400 | Dia90x90x4 |
450 | Dia80x115x3.5 |
600 | Dia85x130x3.5 |
750 | Dia91x140x3.5 |
800 | Dia95x135x4 |
900 | Dia95x160x5 |
950 | Dia100x150x4 |
1200 | Dia100x150x4 |
1250 | Dia100x200x5 |
2000 | Dia120x260x5 |
2500 | Dia155x150x5mm |
Note:
Any other sizes and shapes can be produced according to customers’ specific requirement.
Crucibles with different shapes and various kinds and specifications will be available.
1. standard export packing , wooden case , cartoon case. Crucible for melting aluminium will be protected well.
2. Crucible for melting aluminium can be shipped in any way as you like: by sea ,by air , by express (DHL,FEDEX,EMS,TNT.......)
1) by sea ....... if the order is big/heavy, not urgently needed, by sea would be suggested.
advantage: much cheaper
disatanvage: take longer time.
2)by air.......... advantage: much faster than deliveried by sea
disadvantage: you have to go to airport to take goods and custom yourself.
3)by express....advantage: goods will be delivered faster with door to door service.
disadvantage: a little more expensive
1. Seriously reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well trained professional engineers and staff.
5. As an honest seller, we use superior raw material, advanced machines, skilled technicians to ensure our products finished in high quality and stable feature.
5. Samples are available for your evaluation.
If you are interested in any of our products, please do not hesitate to let me know.
Amy is always here for your service.
