Fully Automatic single head crimping machine (High-speed type)
Introduction:
- 6100pcs/h,functions including:cutting wire automatically, Single-end strip, Double end strip,Single-end twisted, Single-end crimping,Multi-stripping and so on
- LCD,Chinese interface, high-definition, simple operation
- Full CNC digital tuning parameters, accurate and fast.
- Detection featured: without wires, wire tie, terminal testing, Abnormal machine automatic alarm and so on.
- OTP straight mode, transverse mode simple switch,Automatic receiving terminal paper, cut waste terminal.
Parameters:
Type | HS-02S Fully Automatic crimping machine(single head strip) |
Features | Cutting wire automatically,Single-end strip, Double end strip, Single-end twisted, Single-end crimping,Multi-stripping |
Processed wire range | AWG18-AWG32 |
Processing speed | 6100pcs/h(0-100mm) 4600-5800pcs/h(100mm-600mm) |
Wire cutting length | Bold lines 20mm-9999mm, Not twisted wire 8mm-9999mm |
Cutting precision | Less than 1mm+cutting length 0.2% |
Stripping length | 0.1mm-10mm |
Twisted length | 3mm-12mm |
Crimping capacity | 1.8Ton |
Detection function | Without wires, wire tie, terminal testing, Wire Identification (can be installed) |
Machine size | 600X700X1500(mm) |
Power supply | Single-phase power AC220V 50/60HZ |
Our Services
---Purchase guidance
If you are not sure which model is the best option within you budget, please send us the parameter or wire, it’s our pleasure to make a recommendation and comparison models to you.
--- Technical Support
In some cases, professional technical support will be needed , such as parameter meter set-up for difficult-to process wires. HS engineers are here for your assistance.
---After Sale Service
Don’t worry, we are here to help. HS provides life time after sale support to our customers including operation guidance, parts replacement, maintainance support. Just feel free to contact us!
---OEM
HS provides OEM services to our customers.
FAQ:
If u have any question, u can feel free to contact me
