Data Center Intelligent Power Distribution Unit Multi Channel Energy Meter Monitor

Data Center intelligent Power distribution Unit multi channel energy meter monitor

PMAC Series iPDU for Data center and UPS

Standard Function

• Incoming circuit : 1 phase or 2 phase AC power
• Outgoing circuit : 21, 42, 63...168 Branch circuit
• 7’’ Color LCD Touch screen HMI
• Low-low and high-high current alarm and data log
• Installed Monitored SPD surge
• Support Modbus_RTU RS485 communication
• Support Woehner Hot-plug system for MCB
• Monitorting branch circuit ON/OFF status

Optional Function

• K-factor isolation Transformer (K13,K20)
• Static Transfer Switch (STS)
• Support customization

General

• Floor standing installation, suit for raised and non-raised floor environments
• HMI monitors branch circuit from 21 to 168
• Combine PILOT® BPCM for real time power monitoring, historical energy record
• PUE management
• Flexible & Reliable Power Distribution Centre

             - Key components from ABB, SIEMENS, Woehner etc.
             - Hot-plug system, easy maintanance
             - Independent wiring zone, monitoring zone

• Incoming and Outgoing Circuit Power Measuring

             - Incoming circuit : Voltage, Current, Active power, Reactive power, Power factor, Frequency, Active energy, Reactive energy, Demand, Max. Demand, THD (U & I), Leakage current (optional), Temperature (optional)

            - Outgoing circuit : Current, Active power, Reactive power, Power factor, Active energy, Reactive energy, Demand, Max. Demand, THD

• Alarm function

               - Incoming circuit : Alarm for Voltage, Current, Current unbalance
                 (Optional alarm for Leakage current, Temperature alarm)
              - Outgoing circuit : Alarm for current (lo-limit, lo-lo-limit, hi-limit, hi-hi-limit)

Technical Specification

  Dimension

  Order Information

Photos

For more information, please feel free to contact us ~

Data center

Data center

Data center
