Specification
1 ,Power supply: 220V / 50Hz
2 ,Total power: 2.4KW
3 ,Working pressure: 0.4-0.6MPa
4 ,Ambient temperature: 0-50 ℃
5 ,Use Relative humidity: 15-90%
6 ,Battery: 18650
7 ,Battery combinations: a combination of Section 12
8 ,Welding speed:> 1800PCS / h
9 ,Welding nickel plate thickness: 0.1-0.2mm
10 ,Welding nickel sheet width: 2-6mm
11 ,Internal resistance battery voltage accuracy: ± 1%
12 ,Bonding insulating washer thickness: 0.25-0.5mm
13 ,Change mpodel adjustment time: ≤15min
14 ,Nickel sheet welding position accuracy: ≤0.2mm
Feature
1 ,Mobile power automation system for voltage detection resistance, insulation sheet attached to the positive electrode, the battery combination welding.
2 ,All optional functions alone integrally formed combination machines.
3 ,Feeding easy: tilt the hopper on the machine design, Packed batteries can directly feed the whole box, convenient and efficient; hopper can be filled with more than 500 batteries. Further increase in artificial feeding platform to facilitate your company is currently doing with bracket battery discharge.
4 ,Intelligent detection / automatic elimination: use high-precision voltage resistance tester, automatic test battery internal resistance, voltage, reverse polarity, automatically remove the failed battery, improve efficiency, prevent artificial discharge reverse polarity cause a short circuit; the flow of products tested next station stamping posted positive insulating gaskets, insulation pads affixed to products not removed automatically detected.
5 ,Standard I BK300 resistance tester, voltage resistance can set your own upper and lower limits (compatible with a variety of resistance existing factory equipment), computer data storage function can be called at any time to set a good argument.
6 ,Resistance voltage detection function can be turned off, optional.
7 ,Free stickers unglued insulating sheet design: stamping die before the adhesive and separation design, compared to other machines on the market, do not need to constantly spray water from the liquid, does not require frequent cleaning up mold. Bonding position of consistency in the ring hole punch after separating the bottom sheet is aligned with the punching receipts, to reduce the residual gum on application and receipt wheel. SMD consistency, and does not affect subsequent automated welding.
8 ,Insulation pads fit securely precise: batteries positive electrode paste insulating tape firmly, precise holes, does not affect the high-speed positioning welding. Positive insulating mat (0.25-0.5 thick barley yellow paper or paper) the entire volume of incoming automatic punching, close fit, good insulation properties, high-temperature plastic insulation can be compared to the anti-nickel plate burr. Not fit batteries can automatically detect automatically removed.
9 ,Good quality spot welding efficiency: energy-saving core 12 in any combination, both positive and negative batteries spot welding, time-saving. The front end can remain arbitrarily long multicomponent nickel sheet, any single group can stay around long nickel plate, welded and then cut to the structural design, when the parallel combination of batteries will not shake up and down compared to other devices on the market tighter and more solid, can save batteries middle and then dispensing work, when finished eliminate the chance of falling nickel sheet loose.
10 ,The entire spot welding process without human involvement, effectively ensuring the consistency of spot welding effect, while eliminating manual spot welding skills of the workers demands. When discharging the battery pack is placed flat belts, non-flowing style, nickel plate deformation.
11 ,Nickel belt using a disc-shaped nickel belt, reduce waste, nickel plate length can be set free, simple and efficient; nickel sheet width 2-6mm adjustable length position accuracy of <0.2mm, spot welding precision ≤ ± 0.2mm.
12 ,Welding with high performance discharge welder, sparks and no trace. Another optional Japan Miyachi welding current monitor, bad welding automatic alarm. Your company can also be equipped with the original welding, assembly transformation Division I, welder save duplication of investment costs.
13 ,Easy to use: simple debugging device, can store 10 groups of parameters can be called at any time to switch smoothly depending on the battery pack and technological requirements; HuanXing debug <15min; own fault alarm, follow the prompts to clear the fault, easy to understand. Real-time audible alarm and display the fault location and troubleshooting, fault alarm and overheat, overload protection, emergency stop, lack of protection.
14 ,After flowing into the processing is completed the next station, the artificial increase receipts platform to facilitate the production line layout.
FAQ
1 , What is the product ?
It is an automating welding machine for 18650 ,26650 battery , use for 18650 26650 power bank welding .
2 , how is it performance ?
It is automating , more effectioncy , it can replace 10-15 staffs works ,it can help you increase production run ,
and decrease production cost .
3 , what about the quality guarantee and after-sale service ?
we provide one year quality guarantee , full time after-sale service .
4 , we want to open an automating system for lithium battery , how it can do that ?
Yes , we can provide you the battery automating system and solution .
