0.196J Concrete Test Hammer Mortar Strength Testing 1.0 - 25 Mpa

Specifications

TMTeck Manufacturing LTD. (hereafter “TMTeck”) is a leading NDT manufacturers and suppliers in Beijing China and provides innovative technologies and comprehensive know-how to benefit customers in a lot of countries around the world.Till now,TMTeck has been active in the areas of technology-driven inspection solutions that deliver productivity, quality and safety.

     Began from the Ultrasonic Flaw Detector and Coating Thickness Gauge ,now TMTeck has developed more than 10 series of testing instruments, including Ultrasonic Flaw Detector, Coating Thickness Gauge,Hardness Testers,Ultrasonic Thickness Gauge ,their accessories and other NDT instruments. These products are widely used in the analysis of materials that enable our customers to monitor, control and validate their critical processes and applications,also our goods has CE certificates.

Brief introduction:

This instrument is specially used in testing the compressive strength of mortar in building brick component.

Trait:

1)Center rod use imported materials, high precision, wear proof.

2)Shell made from super hard aluminum, perfectly protect instrument from damage on site work, and prolong use life.;

3)Pointer slider is outside ring structure, easy to adjust friction, and assure the equal friction between pointer slider and axis, so that assure the accuracy of instrument. Compare with other brand similar product, it’s better accuracy, longer use life.

Parameter:

Test range: 1.0~25Mpa

Standard impact energy: 0.196J(0.02kgf.m)

Stroke of rebound hammer: 75mm

Friction of pointer slider: 0.4N~0.6N

Sphere radius of rebound pole SR: 25mm

Average rebound hammer on steel anvil: 74±2

Size: Φ54*268mm

Weight: ≈1KG

TMTeck is committed to the maintenance of long-term partnership with our clients by offering unparalleled services, technology advice and assistance. We design and produce a wide range of high performance NDT equipment and accessories. With our continued emphasis on customer focus and global competitiveness, TMTeck has always been one of the top tier of world class companies when it comes to leading in NDT equipment. And we are developing new series products according to the market demand. We can offer good guarantee for our customers.
