WP20 Gasoline Water Pump
US$ 70 - 158
MOQ: 355 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
slong
Model Number:
WP20
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
slong
Model Number
WP20
Output Type
Other
Speed
3600
Frequency
50/60
Rated Power
5KW
Rated Voltage
110/120/220/230/240
Specifications
Gasoline water pumpSuper light OHV gasoline engine as power
Aluminum alloy shell-body
High quality
Bitmap
|
MODEL | WP20 | WP30 | WP40 | |
| INTEL AND OUTLET INSIDE DIAMETER(mm) | 50 | 80 | 100 | ||
| PUMP LIFT(m/foot) | 26/85 | 28/92 | 16/53 | ||
| SUCTION HEIGHT(m/foot) | 8.0/ 26 | 8.0/ 26 | 8.0/ 26 | ||
| PUMP OUTPUT | 550/145 | 1000/264 | 1300/343 | ||
| ENGINE | MODEL | SL160 | SL200 | SL240 | |
| ENGINE TYPE | OHV 4--stroke, forced air-cooled | ||||
| BORE*STROKE(mm) | 68*45/2.68*1.77 | 68*54/2.68*2.13 | 73*58/2.87*2.28 | ||
| DISPLACEMENT(ml) | 163 | 196 | 242 | ||
| COMPRESSION RATIO | 8.5:1 | 8.5:1 | 8.2:1 | ||
| MAX. OUTPUT(Hp/rpm) | 5.5/3600 | 6.5/3600 | 8.0/3600 | ||
| MAX. TORQUE(N.m/rpm) | 10.8/2500 | 13/2500 | 16.7/2500 | ||
| FUEL TANK CAPACITY(L) | 3.6 | 3.6 | 6 | ||
| FUEL CONSUMPTION(g/hp-hour) | 270 | 270 | 2.8 | ||
| ENGINE OIL CAPACITY(L) | 0.6 | 0.6 | 1.1 | ||
| CONTINUOUS OPERATING HOURS | 2.8 | 2.4 | 2.4 | ||
| AIR CLEANER | semi-dry | semi-dry,oil bath, dual, double silent and cyclone type | |||
| IGNITION SYSTEM | Non-contact transistorised ignition(T.C.L.) | ||||
| STARTING SYSTEM | recoil and hand-operated | recoil and hand-operated/electric start | |||
| PACKING | DIMENSIONS(L*W*H)(mm) | 475*385*450 | 515*385*450 | 635*445*550 | |
| NET WEIGHT(kg) | 27 | 30 | 47 | ||
| 20/40FT unit | 355/715 | 325/655 | 176/356 | ||
| MOQ | 355 | 325 | 176 | ||
| 157.94 | |||||
gasoline water pump
