Portable Eddy Current Electrical China Manufacture Conductivity Meter

Began from the Ultrasonic Flaw Detector and Coating Thickness Gauge ,now TMTeck has developed more than 10 series of testing instruments, including Ultrasonic Flaw Detector, Coating Thickness Gauge,Hardness Testers,Ultrasonic Thickness Gauge ,their accessories and other NDT instruments. These products are widely used in the analysis of materials that enable our customers to monitor, control and validate their critical processes and applications,also our goods has CE certificates

TMD-102 is a kind of eddy current electrical conductivity meter, which is designed for quick & convenient measurement of material property, such as material separate,quality control,material state check and so on. It uses the electromagnetism testing principle. Testing objects focus on non-ferromagnetic material.

Features:

1.The meter uses 60 KHz (aviation industry standard) to inspirit, and the testing data can be read in two kinds of unit: %IACS or MS/m.

2. Its big typeface, the back light illumination designs are advantageous for users to take the testing data even in low light condition.

3. It uses the high property battery to make sure it keeps more running time, and because of its mini-size, it is easy to carry and to grasp hold.

4. The design of the meter is more advantages: user can replace the probe in the outdoor, don’t need to return to the company to adjust the probe into matching the meter

Applications:

1.Test the conductivity of aluminum, copper and other non-ferrous magnetic metal in the processing industry.

2.In the aerospace and automotive industries,monitor the process of heat treatment, the strength and hardness of aluminum alloy.

3.Test the conductivity aluminum when it has not been oxidized.

4. Test the purity grade of materials.

5. Test materials resistivity.

6. Material Thermal Performance analysis

Technical parameters:

Note: The conductivity measurements automatically rectified to the value at 20°C.
