Specifications
Cupro nickel 70/30 90/10 barASTM B171 ASME SB151 MIL C-15726E/F
C70600 C71500 bar
C71500 Copper Nickel Alloy Bar
C71500 Copper Nickel Alloy Bar has excellent resistance to bio-fouling and corrosion in sea-water with some variations in the performance of the alloys under different conditions.
Chemical composition %
Alloy |
Name |
Copper |
Nickel |
Iron |
Lead |
C71500 |
70-30 Copper Nickel |
69 max |
29.0 – 33.0 |
0.4 – 1.0 |
0.05 max |
Properties
Alloy |
Density |
Thermal conductivity |
TEC |
Electrical resisitivity |
Elastic modulus |
Yield strength |
Tensile strength |
70-30 |
8.95 |
29 |
16 |
34 |
152 |
125 |
360 |
Specification
Sheet |
Pridametal |
Thickness: 0.05mm and above |
Applications
- Desalination
- Underwater tubing
- Exchangers
- Marine hardware
Manufacture Process
The manufacture of sheet is started with producing ingot by advanced vacuum melting process. The sheet production includes forging, rolling, annealing, acid-washing, polishing, etc. The sheet is produced to the required sizes. From the ingot to the final sheet, manufacture process is operated with high standard quality control system. There will be quality test for each batch of product, such as test to thickness tolerance, content, hardness, etc.
