1000V 40kA DC SPD DC Lightning Arrester for Photovoltaic
US$ 22.3 - 26.3
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ZJBENY
Model Number:
BU-40/3
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DC Surge Arrester for Photovoltaic TUV CE 1000V 40kAUS$ 22.3 - 26.3MOQ: 50 Pieces -
DC SPD Surge Protective Device For Solar System SaftyUS$ 22.3 - 26.3MOQ: 100 Pieces
-
DC Surge Protective Device for Solar Application TUV CE 1000V 40kA IEC 50539US$ 22.3 - 26.3MOQ: 50 Pieces
-
1000V DC Surge Protector/DC SPDUS$ 22.3 - 26.3MOQ: 50 Pieces
-
dc Lightning Protect Devices for Solar SystemUS$ 22.3 - 27MOQ: 50 Pieces
Place of Origin
Zhejiang, China
Brand Name
ZJBENY
Model Number
BU-40/3
Product Description
1000V 40kA DC SPD DC lightning arrester for photovoltaic Features:
Ø Meet the exclusive standard: IEC50539-11 for PV Surge Protection Device
Ø Plug In module
Ø Rated voltage: 1000VDC
Ø Maximum discharge currents( 8/20μs) : 40kA
Ø Nominal discharge current s: 20kA
Ø Ambient temperature: -30°C—70°C
Ø Remote signal contact: Optional
Picture:
Technical Datas:
| Type | BU-40/3 | |
| Poles | 3P | |
| Open circuit voltage Uoc | DC 1000V | |
| Max. continuous working voltage Ucpv | DC 1000V | |
| Nominal discharge current | 20kA | |
| Maximum discharge current | 40kA | |
| Indicator | Default | |
| Plug-in module | Default | |
| Remote signal contact | Optional | |
| Wiring capacity | 4-25mm2 | |
| Installation way | TH35-7.5/DIN35 Rail installation | |
| Ambient temperature | -30~70°C | |
| RH(relative humidity) | 30~90% | |
Packaging & Shipping
Packing Details:
All goods are well packed before sending or shipping!!
Company Information
Workshop:
- Our workshop is totally dust-free with 6S management methods.
- All workers are strictly trained to be qualified for every position.
Test Equipment:
We have professional test machines to ensure all products are qualified before present them to the customers.
All test machines are well maintained and measured to guarantee the accuracy, and the
specialized tester saves all record for tracking.
Exhibition Show:
We attended many oversea exhibitions in since last year. Our profesional products and service attracted many customers from different countries.
Customer Visit:
Many customers showed interest to our products and established cooperation relationship after visiting our company.
1000V 40kA DC SPD DC lightning arrester for photovoltaic 1000V 40kA DC SPD DC lightning arrester for photovoltaic 1000V 40kA DC SPD DC lightning arrester for photovoltaic 1000V 40kA DC SPD DC lightning arrester for photovoltaic 1000V 40kA DC SPD DC lightning arrester for photovoltaic
