Low Frequency Ups 8-400kva

Low Frequency Ups 8-400kva thumbnail-1
Low Frequency Ups 8-400kva photo-1
US$ 500 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HKSANTEK
Model Number:
HT HM
Contact Supplier Request Quote Chat Now
Shenzhen Santek Power Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HKSANTEK
Model Number HT HM
Phase Three Phase
Protection Short Circuit
Weight 100kgs
Output Voltage 380VAC
Type On-line
Application Security / Monitoring / Alarm

Specifications

1.10KVA to 400KVA Low Frequency Ups
2.Pure sine wave output
3.Excellent load feature
4.Perfect protection

HT-HM series(3/3) Low Frequency Online Ups



Large-medium computer data center, industry process and other mission-critical equipment.



Features:

  • Double conversion online technology
  • Modularity
  • Double CPU control
  • Static bypass
  • Manual maintenance bypass
  • Wide input voltage range
  • LCD with control panel
  • Advanced battery management
  • Parallel redundant, paralleled up to 8 units
  • Auto sensingFull protections against over-discharge, over charge, over load
INDUSTRY UPS(parallel/redundant): G-HM,G-HT  8000VA-200000VA

Model No. HM8 HM10 HM15 HM20 HM30 HT10 HT20 HT30 HT40 HT60 HT80 H100 H120 H160 H200
Power Capacity(VA) 8K 10K 15K 20K 30K 10K 20K 30K 40K 60K 80K 100K 120K 160K 200K
Power Capacity(W) 6.4K 8K 12K 16K 24K 8K 16K 24K 32K 48K 64K 80K 96K 128K 160K
Input
Nominal Voltage 380VAC or 190VAC (3 phases 4 wires and ground)
Voltage Range 304-456VAC
Frequnency Range 50Hz or 60Hz ±5%
Power Factor over 0.97
Phase 3 Phases + GND
Max I/P current 15A 18A 27A 36A 54A 18A 37A 55A 72A 108A 130A 160A 190A 245A 310A
Output
Voltage 120VAC/230VAC±1% 380VAC/400VAC/415VAC±1% or 192VAC±1%
Frequnency  Sync to input(line mode),50Hz or 60Hz±0.05
Waveform Type pure sinewave
Phase 3 Phases 4 wires + GND
Voltage Distortion ≤3% for linear load
Overload Capacity 110% for 300mins or 125% for 10mins or 150% for 1min then transfer to bypass & alarm
Power Factor 0.8
Crest Power 3 times of ratings
Batteries
type Maintenance-free sealed Lead-Acid battery
Nominal DC Voltage 384VDC 432VDC 480VDC
Charging Time 8-10 hours for 90% capacity after full discharge
Transfer time 0 ms(line to battery mode)
Protections overload,short circuit,over temperature,surge,line abnormal
Display
LED Operation mode(online,battery,bypass),battery capacity,abnomal,overload
LCD I/P voltage & frequency,battery volt,O/P voltage & frequency,
load percentage,Operation mode,temperature inside
Efficiency over 0.85 for whole unit
Comunications & Management
Interface Port RS-232
Intelligent Slot Dry Contact/EPO/SNMP Card (optional)
Bypass Static state + manual maintenance bypass
Enviromental
Operation Enviroment 0-40°C
Storage Enviroment  -25°C~55°C
Relative Humidity 0-95%RH(non-condensing)
Audible Noise less 55dB less 60dB less 65dB less 70dB
Altitude Nominal power output for less 1000m, reduce output 1% for increase of 100m,Max 4km
Physical
Net Weight(KG) 190 200 220 240 269 223 260 336 351 497 556 756 901 1300 1350
Gross Weight(KG) 247 256 265 288 305 280 317 393 408 574 633 856 1001 1400 1450
Dimension,DxWxH(mm)
for "S" type		 555 X 725 X 1220 800X745X1400 1070X745X1400 1420X745X1810
Optional Components Isolation transformer,Parallel modules,Harmonic wave filter,SNMP adapter,Monitoring software
Safety Standard EN50091-1 EN50091-2 CLASS A, IP20
*Specifications are subject to change without prior notice.
