ONLINE UPS LCD SCREEN

ONLINE UPS LCD SCREEN thumbnail-1
ONLINE UPS LCD SCREEN photo-1
US$ 80 - 200 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HKSANTEK
Model Number:
Castle Series
Contact Supplier Request Quote Chat Now
Shenzhen Santek Power Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HKSANTEK
Model Number Castle Series
Phase Single Phase
Protection Overvoltage
Weight 14-30KGS
Output Voltage 110V/220VAC ± 2%
Type On-line
Application Telecommunications

Specifications

Online 1 to 3kva ups
Zero Conversion
Wide Input Voltage and Frequency Range
Automatic Adjustment to 50Hz/60Hz Power Supply

UPS

Key Features

DSP Technology

The application of DSP enhances the stability and quality of UPS.

Green and Environment-friendly

As a green and environment-friendly product, the series is consistent with all requirements of EU environmental directive RoHS and the National Pollution Control Methods on Electrical Information Products. No harm will be caused to the human health under the normal condition.

Wide Input Voltage and Frequency Range

The wide input voltage and frequency range ensures normal power supply even under the worst environment. It reduces the discharging times and prolongs the battery life.

Zero Conversion

While the commercial power supply is not steady, the conversion time of UPS mode is zero, guaranteeing the safety and reliability of load operation.

Automatic Adjustment to 50Hz/60Hz Power Supply System

It can automatically recognize and adjust to 50Hz/60Hz supply system and accommodate the needs of different systems.

Strong Expansion Function

The intelligent slot offers diversified expansion function. Winpower, CMC monitoring card, SNMP card, RS485, AS400 and EMD can be selectively installed.

Load Power Factor 0.8

It is consistent with the future trend of power supply with stronger loading capacity.

Combination with Generators

A wide range of input voltage and frequency effectively isolates the harmful power and provides the load with clean, safe and steady power.

Technical Specifications

Product Series
CASTLE
Model
BS1K
BS2K
BS3K
Rated Power
VA/W
1kVA / 0.7kW
2kVA / 1.4kW
3kVA / 2.1kW
Input
Nominal Voltage
110V/220VAC
Voltage Range
60V~136V/115 ~ 300VAC
Frequency Range
46~54Hz(default), user adjustable within 40~60Hz
Power Factor
0.97
Connection
IEC320-10A inlet
IEC320-16A inlet
Output
Voltage
110V/220VAC ± 2%
Frequency
46~54Hz or 50Hz ± 0.2Hz (Line mode)
50Hz ± 0.2Hz ( Battery mode)
Waveform
Sine Wave
Distortion
3%
4%
Overload Capability
108%~150% for 30 sec., ³150% for 300 ms
Current Crest Ratio
3:1
Connections
IEC320 * 4
IEC320 * 6
IEC320 * 3 and
Terminal Block
Battery
Type
Sealed, Maintenance free, Lead-Acid
Quantity
3 pieces
8 pieces
Back-up Time (Full load)
5 min
9 min
5 min
Recharge Time
5 hrs to 90% of capacity after full load discharge
Bypass

Automatic Transfer
on overload and UPS failure
Before UPS Power-on
Default NO, user adjustable to YES
Voltage Range
80~264VAC (Default), user adjustable within 80~286VAC
Transfer Time
0 ms; less than 4 ms from inverter to bypass and vice versa
LED Indicators
Status
Load level / Battery level, Battery , Utility Power, Inverter, Bypass, Overload, Fault
Audible Alarm
Bypass, On battery mode, Battery low, Overload, Fault
Acoustic Noise
At 1 meter distance
45 dBA
50 dBA
Communications
DB-9 Port
RS-232 Serial Interface
Intelligent Slot
Options: WebPower, AS400 Card or WinPower CMC
Network Surge Protection
RJ45 I/O port available for network or Fax/Modem
Environmental
Operating Temperature
0 ~ 40°C
Operating Humidity
20 ~ 90% non-condensing
Weight
Net (Kg)
13
31.5
32
Dimensions
W x D x H (mm)
145 x 400 x 220
192 x 460 x 348
