New Industrial Frequency UPS/Pure Sine Wave Home Inverter UPS 25KVA /Online UPS
- 1000 Piece / Pieces per Month
- SHENZHEN
- T/T L/C D/P D/A Credit Card PayPal
-
Stackable Rack Energy Storage System Home energy storage system 5kWh 10kWh 15kWh and 20kWh
-
Schneider Electric UPS
-
Solar Generator With 5000W Inverter Portable Pull Rod LiFePO4 Battery Power Station
-
3000W Power bank EPS AC220V portable energy storage home power supply
-
5KW Outdoor Mobile Portable power station 220V Type-C DC12V DC5V Output UPS
-
500W portable UPS LFP Battery Solar Generator Backup Power Station
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | HK SANTEK | Model Number: | G-MS 25KVA |
| Phase: | Other, Three Phase, Three Phase | Protection: | Other, Overvoltage, Overvoltage | Weight: | 326-356KG |
| Output Voltage: | 220/230/240VAC, 220/230/240VAC | Type: | Other, On-line, On-line | Application: | Other, Networking, Medical |
Product Description
New Industrial Frequency UPS/Pure Sine Wave Home Inverter UPS 25KVA /Online UPS
Application:
Critical servers, storage appliance and other networking equipments
Features:
True online double conversion design providing all power protection
Sine wave PWM function
IGBT inverter design
Wide input voltage range
Pure sine wave output with less than 3% THD
Generator compatible
Cold start
Load/battery power meter display
Overload, online, battery status LED/LCD
Advanced battery management
Automatic charging in UPS off mode
Zero transferring time on any mode transfer
Smart RS-232 communication port
Optional SNMP card
| SPECIFICATION | ||||||
| MODEL | 6KS | 10KS | 15KS | 20KS | 25KS | 30KS |
| RATED POWER | 6KVA | 10KVA | 15KVA | 20KVA | 25KVA | 30KVA |
| (VA/W) | 4.8KW | 8KW | 12KW | 16KW | 20KW | 24KW |
| INPUT | ||||||
| INPUT VOLTAGE | 380VAC(3 phases) or 190VAC(3 phase) | |||||
| VOLTAGE RANGE | 304-456VAC or 152-228VAC | |||||
| FREQUENCY | 50/60Hz±5% | |||||
| Power Factor | >0.8 | |||||
| Max. input current | 10A | 16A | 24A | 32A | 40A | 56A |
| OUTPUT | ||||||
| Voltage | 230VAC/120VAC±1% | |||||
| Frequency | Sync to input(line mode),50Hz or 60Hz±0.05 | |||||
| Waveform Type | pure sinewave | |||||
| Power Factor | 0.8 | |||||
| THD | <3% with linear load | |||||
| Overload Capability | 110%-150% for 5 minutes or >150% for 300ms then transfer to bypass & alarm | |||||
| Current Crest Ratio | 3:1(max) | |||||
| overall efficiency | >90% | |||||
| Transfer Time | ||||||
| From inverter to battery | 0ms | |||||
| Battery | ||||||
| Voltage | 192VDC | 240 | ||||
| Recharge Time | 8~10 hrs to 90% of capacity after full load discharge | |||||
| LED /LCD Indications | ||||||
| LED | Battery level,utility power,inverter,bypass,Fault, overload | |||||
| LCD | Input/output voltage,Frequency,battery voltage,load percent,Tempreature | |||||
| Communications | ||||||
| interface | RS232 SNMP(optional) | |||||
| Protection Standard | ||||||
| Surge Protection | lEEE527B | |||||
| Noise protection | FCC.A | |||||
| Working conditon | ||||||
| Temperature | 0~40°C | |||||
| Humidity | 0~95%°C non-condensing | |||||
| Storage tempreature | -25°C~55%°C | |||||
| Acoustic Noise | <55dB(at 1 meter distance) | |||||
| Weight | ||||||
| N.W(Kg) | 118 | 155 | 240 | 297 | 326 | 336 |
| G.W(Kg) | 138 | 175 | 265 | 327 | 356 | 366 |
| W×D×H mm | 310X590X870 | 410X670X935 | 725X430X 1180 | |||
| S: long backup | ||||||
| YD/T 1095-2000 | ||||||
Pure Sine Wave Home Inverter UPS 25KVA
Produce line
Quality Control Equipment:
Applications:
Computer center,network center,communication system,automation control system or other critical system.
About the company
HKSANTEK'S Quality Policy
Qaulity is a system, quality is a project,it can contains all the activities of the whole factory,HKSANTEK's belief is "behave
ourseleves firstly, then keep the materials &produce in good level, finally assure the products's quality.everyactivity
effect the quality, so every one is the QC staff in factory.
All the running of HKSANTEK Company is compliant with the ISO9001-2008 and ISO 14001-2004
