6KVA/4.8KW 3phase Industrial Frequency Online Ups IGBTand Double Conversion Deisign
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
hksantek
Model Number:
G-MS
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20KVA/16KW 3phase Industrial Frequency Online UpsNegotiableMOQ: 10 Pieces -
Pure Snie Wave DC AC Inverter With Charger off Grid Inverter 8000w to 12000wUS$ 130 - 400MOQ: 10 Pieces
-
HKSANTEK 10kva -200kva Three Phase UpsUS$ 99 - 299MOQ: 1 Unit
-
High Quality 1KVA to 400KVA Low Frequency UpsNegotiableMOQ: 10 Sets
-
High Performance 1KVA to 400KVA Low Frequency UpsNegotiableMOQ: 10 Sets
Place of Origin
Guangdong, China
Brand Name
hksantek
Model Number
G-MS
Phase
Three Phase
Protection
Overvoltage
Output Voltage
220VAC
Type
On-line
Application
Medical
Specifications
6KVA/4.8KW 3phase industrial frequency online ups IGBTand double conversion deisign6KVA/4.8KW 3phase industrial frequency online ups IGBTand double conversion deisign
Application:
Critical servers, storage appliance and other networking equipments
Features:
True online double conversion design providing all power protection
Sine wave PWM function
IGBT inverter design
Wide input voltage range
Pure sine wave output with less than 3% THD
Generator compatible
Cold start
Load/battery power meter display
Overload, online, battery status LED/LCD
Advanced battery management
Automatic charging in UPS off mode
Zero transferring time on any mode transfer
Smart RS-232 communication port
Optional SNMP card
| SPECIFICATION | ||||||
| MODEL | 6KS | 10KS | 15KS | 20KS | 25KS | 30KS |
| RATED POWER | 6KVA | 10KVA | 15KVA | 20KVA | 25KVA | 30KVA |
| (VA/W) | 4.8KW | 8KW | 12KW | 16KW | 20KW | 24KW |
| INPUT | ||||||
| INPUT VOLTAGE | 380VAC(3 phases) or 190VAC(3 phase) | |||||
| VOLTAGE RANGE | 304-456VAC or 152-228VAC | |||||
| FREQUENCY | 50/60Hz±5% | |||||
| Power Factor | >0.8 | |||||
| Max. input current | 10A | 16A | 24A | 32A | 40A | 56A |
| OUTPUT | ||||||
| Voltage | 230VAC/120VAC±1% | |||||
| Frequency | Sync to input(line mode),50Hz or 60Hz±0.05 | |||||
| Waveform Type | pure sinewave | |||||
| Power Factor | 0.8 | |||||
| THD | <3% with linear load | |||||
| Overload Capability | 110%-150% for 5 minutes or >150% for 300ms then transfer to bypass & alarm | |||||
| Current Crest Ratio | 3:1(max) | |||||
| overall efficiency | >90% | |||||
| Transfer Time | ||||||
| From inverter to battery | 0ms | |||||
| Battery | ||||||
| Voltage | 192VDC | 240 | ||||
| Recharge Time | 8~10 hrs to 90% of capacity after full load discharge | |||||
| LED /LCD Indications | ||||||
| LED | Battery level,utility power,inverter,bypass,Fault, overload | |||||
| LCD | Input/output voltage,Frequency,battery voltage,load percent,Tempreature | |||||
| Communications | ||||||
| interface | RS232 SNMP(optional) | |||||
| Protection Standard | ||||||
| Surge Protection | lEEE527B | |||||
| Noise protection | FCC.A | |||||
| Working conditon | ||||||
| Temperature | 0~40°C | |||||
| Humidity | 0~95%°C non-condensing | |||||
| Storage tempreature | -25°C~55%°C | |||||
| Acoustic Noise | <55dB(at 1 meter distance) | |||||
| Weight | ||||||
| N.W(Kg) | 118 | 155 | 240 | 297 | 326 | 336 |
| G.W(Kg) | 138 | 175 | 265 | 327 | 356 | 366 |
| W×D×H mm | 310X590X870 | 410X670X935 | 725X430X 1180 | |||
| S: long backup | ||||||
| YD/T 1095-2000 | ||||||
