Help CenterMetal Detector Portable From Solid NDT Company
Related Products
-
Solid Tools for Measuring and TestingNegotiableMOQ: 1 Set -
1 Twist Testing MachineUS$ 200 - 750MOQ: 1 Set
-
Volume Measuring Equipment From Solid(Beijing) Technology Co.,LtdNegotiableMOQ: 1 Set
-
Solid 2013 Newest Velocity Gauge OperationNegotiableMOQ: 1 Set
-
Solid Newest Pearl Weld Digital Portable Nodularity ManualNegotiableMOQ: 1 Set
Specifications
1 Nodularity guage using2 Nondestructive Velocity Testing
3 Auto Probe Zeroing Calibration Without Block
Spercifacation
|
Principle |
Ultrasonic(Pulse-Echo/Echo-Echo) |
Dimension (mm) |
165×82×30 |
|||
Resolution |
0.1mm(> 100mm)/0.01mm(<100mm) |
Accuracy |
±(0.5%H+0.01)mm |
|||
Nodularity |
Percentage: 50~100%,1% Grade:1-6 |
Thickness Range |
0.75-50mm |
|||
Velocity |
1000~9999m/s |
Weight |
250g |
|||
Calibration |
Auto Sound-Velocity-Calibration |
Measuring Range |
Noarmal:0.75-40mm Coating: 2-25mm |
|||
Auto Probe Zeroing Calibration |
Pulser |
150V Negative Pulse |
||||
Indicator |
Probe Connection Indicator |
Receiver |
Gain |
High/Low/Auto |
||
Coupling Indicator |
Bandwidth |
0.5-15MHz |
||||
Environment |
Temperature:-20°C~70°C |
Measuring |
Result Showing |
Online Statistic/Velocity |
||
Humidity:5%~90% |
Statistic |
Online:Max Min ,Standard Devration |
||||
DISLAY |
LCD |
High-Contract 128*64 |
File: Max, Min AVG, mean square error |
|||
|
Beautiful printed characters, Number , Symbol, High Brightness EL Backlight |
Alarm |
Threshold Acoustooptical Alarm |
||||
Memory |
Files |
1000 groups |
||||
Thickness Logging |
1000 data sets/group ,liner |
|||||
|
Update Rate |
Single Point: 5 times/s |
USB Storage |
Connection USB is allowed, convenient to read thickness values |
|||
Scan Mode: 25times/s | ||||||
More Details
USB Parts
Series Products
Our Certification
We established in 2006. We are a professional manufacturer for non-destructive testing (NDT) instruments which includes hardness tester, ultrasonic thickness gauge, ultrasonic flaw detector etc.
