Solid Popular Plastic Ultrasonic Thickness Gauge
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
Solid
Model Number:
Upad
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solid 2013 Newest Upad Cast Steel Thickness MeasuringNegotiableMOQ: 1 Piece -
Solid 2013 Newest Upad Alloy Thickness MeasuringNegotiableMOQ: 1 Piece
-
Solid 2013 Newest Upad Iron Thickness MeasuringNegotiableMOQ: 1 Piece
-
Solid 2013 Newest Upad Iron Ultrasonic Thickness MeasuringNegotiableMOQ: 1 Piece
-
Solid 2013 Newest Upad Cooper Ultrasonic Thickness MeasuringNegotiableMOQ: 1 Piece
Place of Origin
Beijing, China
Brand Name
Solid
Model Number
Upad
Specifications
1ultrasonic thickness gauge2Resolution:0.1mm(>100mm)/0.01mm(<100mm)
3Measuring Metal Eliminating the Effect of c
Solid popular plastic ultrasonic thickness gauge
Feature
Solid Cpad T200 Portable coating thickness gauge is designed for measuring the thickness of coating. which is applied to test pianting thickness of the car . The feature for this meter is fast , non-destructive and accurate. Cpad Coating Thickness Gauge is applied in many areas, such as electroplating industry, corrosion protection, aerospace industry, automotive car industry, ship building industry , light industry and inspection, etc.
| Principle | Ultrasonic(Pulse-Echo/Echo-Echo) | Dimension (mm) | 165×82×30 | ||||
| Resolution | 0.1mm(> 100mm)/0.01mm(<100mm) | Accuracy | ±(0.5%H+0.01)mm | ||||
| Velocity | 1000~9999m/s | Weight | 250g | ||||
| Calibration | Auto Sound-Velocity-Calibration | Measuring Range | Noarmal:0.75-40mm Coating: 2-25mm | ||||
| Auto Probe Zeroing Calibration | Pulse | 150V Negative Pulse | |||||
| Indicator | Probe Connection Indicator | Receiver | Gain | High/Low/Auto | |||
| Coupling Indicator | Bandwidth | 0.5-15MHz | |||||
| Environment | Temperature:-20°C~70°C | Measuring | Result Showing | Online Statistic/Velocity | |||
| Humidity:5%~90% | Statistic | Online:Max Min ,Standard Devration | |||||
| DISLAY | LCD | High-Contract 128*64 | File: | Max, Min AVG, mean square error | |||
| Beautiful printed characters,Number, Symbol, High Brightness EL Backlight | Alarm | Threshold Acoustooptical Alarm | |||||
| Thickness Logging | 1000 data sets/group ,liner | Memory | Files | 1000 groups | |||
| Update | Single Point: 5 times/s | USB Storage | Connection USB is allowed, convenient to read thickness values | ||||
| Rate | |||||||
| Scan Mode: 25times/s | Standard Package | ||||||
| Input/Output | Probe Cable | LEMO 00 (C5) x2 | Main Body | 1 | |||
| Communication | USB | Probe | 1 | ||||
| Language | Chinese /English | Manuel | 1 | ||||
| Unit | mm/inch | Carrying Case | 1 | ||||
| Power supply | Battery | 1.5V AAA x4 | Coupling paste | 1 | |||
| Working Time | 200 hours | Battery | 1 | ||||
Ability
used coating used coating thickness used coating thickness gauge used coating thickness gauge price used coating thickness gauge apply used coating thickness gauge manual used coating thickness gauge operation used coating thickness measuring used coating thickness gauge used
