Product Details
Place of Origin: | Beijing, China | Brand Name: | Solid | Model Number: | Upad |
Product Description
Beijing best seller ultrasonic thickness tester
Feature
SOLID ultrasonic thickness gauge is used for measuring the thickness of nonmetallic plate indirectly, especially for steel sheet , pipe , iron . This gauge is to measure the Steel Sheet thickness mainly by using distribution characteristics of electromagnetic field and possesses functions of thickness measurement, data analysis, data storage & output etc. It is a kind of intelligent thickness measuring instrument that is portable, convenient and accurate.
Specification
Principle | Ultrasonic(Pulse-Echo/Echo-Echo) | Dimension (mm) | 165×82×30 | ||||
Resolution | 0.1mm(> 100mm)/0.01mm(<100mm) | Accuracy | ±(0.5%H+0.01)mm | ||||
Velocity | 1000~9999m/s | Weight | 250g | ||||
Calibration | Auto Sound-Velocity-Calibration | Measuring Range | Noarmal:0.75-40mm Coating: 2-25mm | ||||
Auto Probe Zeroing Calibration | Pulse | 150V Negative Pulse | |||||
Indicator | Probe Connection Indicator | Receiver | Gain | High/Low/Auto | |||
Coupling Indicator | Bandwidth | 0.5-15MHz | |||||
Environment | Temperature:-20°C~70°C | Measuring | Result Showing | Online Statistic/Velocity | |||
Humidity:5%~90% | Statistic | Online:Max Min ,Standard Devration | |||||
DISPLAY | LCD | High-Contract 128*64 | File: | Max, Min AVG, mean square error | |||
Beautiful printed characters,Number, Symbol, High Brightness EL Backlight | Alarm | Threshold Acoustooptical Alarm | |||||
Thickness Logging | 1000 data sets/group ,liner | Memory | Files | 1000 groups | |||
Update | Single Point: 5 times/s | USB Storage | Connection USB is allowed, convenient to read thickness values | ||||
Rate | |||||||
Scan Mode: 25times/s | Standard Package | 1 | |||||
Input/Output | Probe Cable | LEMO 00 (C5) x2 | Main Body | 1 | |||
Communication | USB | Probe | 1 | ||||
Language | Chinese /English | Manuel | 1 | ||||
Unit | mm/inch | Carrying Case | 1 | ||||
Power Supply | Battery | 1.5V AAA x4 | Coupling paste | 1 | |||
Working Time | 200 hours | Battery | 1 |
