Fiber Optical Isolator for EDFA
US$ 25 - 58
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
LINKET
Model Number:
1310/1550nm Isoator
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Shenzheng
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Optical Fiber Switch 1*4 for OADMUS$ 25 - 620MOQ: 2 Pieces -
Optical Fiber Switch 8 PortsUS$ 25 - 620MOQ: 2 Pieces
-
1*2 Optical Switch for System MonitoringUS$ 25 - 620MOQ: 2 Pieces
-
Multi-channel Optical Ethernet SwitchUS$ 25 - 620MOQ: 2 Pieces
-
Fiber Optic Isolator Polarization Insensitive 1310/1550nmUS$ 25 - 58MOQ: 2 Pieces
Place of Origin
Jiangsu, China
Brand Name
LINKET
Model Number
1310/1550nm Isoator
Specifications
1 High Isolation2 Low Insertion Loss
3 High Return Loss
4 Optical path epoxy free
5 Low PDL
1 Applications:
---Fiber Optic Amplifiers
---CATV Fiberoptic Links
---Fiberoptic System Testing
---Fiberoptic LAN Systems
---Telecommunications
2 Technical Specs:
| Parameter | Specification | |||
| Operating Wavelength (nm) | 1310/1550 | |||
| Operating Wavelength Range(nm) | ±15 | ±30 | ||
| Type | Single | Dual | ||
| Grade | P Grade | A Grade | P Grade | A Grade |
| Type Insertion Loss 23°C | 0.35 | 0.45 | 0.5 | 0.6 |
| Insertion Loss (max.) 23°C | 0.55 | 0.65 | 0.8 | 0.9 |
| Typical Isolation(min) (dB) | 40 | 38 | 55 | 50 |
| Minimum Isolation(min)* (dB) | 30 | 29 | 46 | 42 |
| Max. PDL (dB) | 0.08 | 0.1 | 0.08 | 0.1 |
| PMD(ps) |
0.25(0.05 available upon request) | 0.1 | ||
| Return loss (In/Out) (dB) | 60/55 | |||
| Maximum Optical Power(mw) | 500 | |||
| Maximum Tensile Load(N) | 5 | |||
| Operation Temperature(°C) | –5~75 | |||
| Storage Temperature (°C) | –40~+85 | |||
| * At 23° C over bandwidth | ||||
3 Workshop Overview
4 ISO 9001 Certificate and TLC Certificate for PLC Splitter
