Mini CWDM Mux/Demux Module

Name: Mini CWDM Mux/Demux Module
Brand: LINKET
Price: USD $50 - 380 / Piece

FOB Price

USD $50 - $380 / Piece

2 Pieces(Min.Order)

Product Details

Place of Origin:

Jiangsu, China

Brand Name:

LINKET

Model Number:

1*8ch Mini CWDM

1. Why choose LINKET ?

----- Our customers: FiberHome, Fujikura, HUAMAI, KEXIN, FOCI, Sunsea, TD Telecom

----- Largest PLC Splitter Manufacturer in China: 10Kpcs/day, 40% market share

----- Most Professional on Key Technology: Wafer Dicing and Coupling

----- Import wafer only from South Korea and Reliable relationship with wafer suppliers

----- Direct Factory Price

2. Technical Specs for CCWDM

Item	Unit	Values
Channels Number	-	4					8
		Min.	Typ.			Max.	Min.	Typ.		Max.
Channel Space	nm	20
Central Wavelength		1271/1291/1311/1331/1351/1371/1391/1411/1431/ 1451/1471/1491/1511/1531/1551/1571/1591/1611
Operating wavelength	nm	1260-1460 or 1460-1620 or 1260-1620
Passband	nm	λITU±6.5
CWDM Channel Insertion Loss	dB	0.8		1.3	1.5		1.0	2.2	2.8
Adjacent Channel Isolation	dB	30		-	-		30	-	-
Non-adjacent Channel Isolation	dB	40		-	-		40	-	-
Polarization Mode Dispersion	ps	-		-	0.2		-	-	0.2
Polarization Dependent Loss	dB	-		-	0.2		-	-	0.2
Return Loss	dB	40		45	-		40	45	-
Directivity	dB	50		55	-		50	55	-
Insertion Loss Temperature Sensitivity	dB/°C	0.005		-	-		0.005	-	-
Wavelength Temperature Shifting	nm/°C	0.002		-	-		0.002	-	-
Power (max.)	mW	-		300	500		-	300	500
Operation Temperature	°C	-10~+70
Storage Temperature	°C	-40~+85
Package Dimension	mm	50×28.8×6.5 or customized

Note: 1. All parameters are for device without connectors.

2. Special specifications can be customized according to customer requirements.

3. Different Models

Company Information

1. Our Advantage- Integrated Total Chain, Direct Factory Price

Production/Manufatcurer Level	Cut Wafer and Produce Chips	Make V-Groove	Make Fiber Array	Coupling	Produce Patch Cords and Install Connector
1st Level (LINKET)	√	√	√	√	√
2nd Level		√	√	√	√
3rd Level			√	√	√
4th Level				√	√
5th Level					√
LINKET intergrates the total chain, is the top-level PLC Splitter manufacturer in China. With over 10K/day production capacity, our PLC Splitters occupy over 40% market share in China.

2. CE, TLC, ISO 9001 Certified

3. Workshop Overview

Changzhou LINKET Electronics Technology Co., Ltd.: Contact nameStephanie Shen; Phone86-519-86221538; AddressLongwo Rd 3# , Wujin South High-Tech Zone, Changzhou ,China. Changzhou,Jiangsu
