Help CenterAZ-1325 Large-format Laser Cutting Bed Textile Fabric Laser Cutting Machine With 80w 100w 150w
Related Products
-
Automatic Metal Steel Cutting Laser Machine Upto 2mmUS$ 70,000 - 150,000MOQ: 1 Set -
AZ-2513 200 W Stainless Steel Die Board Metal and Non-metal Laser Cutting MachineUS$ 70,000 - 150,000MOQ: 1 Set
-
AZ-1325 500W 0-8mm Automatic Sheet Steel Laser Cutting Machine for SaleUS$ 70,000 - 150,000MOQ: 1 Set
-
AZ-1325 500W Gold Laser Cutting Machine Silver Laser Cutting Machine Cnc Laser Cutting Steel MachineUS$ 70,000 - 150,000MOQ: 1 Set
-
AZ-1325 500w Fiber Laser Cutting Engraving Machine for MetalUS$ 48,000 - 80,000MOQ: 1 Set
AZ-2513H Series Laser Area Flat Bed Cutting&Engraving Machine
Model Features
1. Gantry structure and flat bed design shorten the transmission path of laser, suitable for laser processing in large working area
2. The control system of cutting and engraving, which is developed by ourselves is able to actively and intelligently optimize the cutting and engraving path
3. Using imported high precision liner guide to ensure of high accuracy liner path cutting and engraving
4. Using special aluminum blade table, can adjust the aperture size, and reduce the reflection in cutting processing
Applicatle Industry
It is widely applied to garment industry, textile, advertisement, craft gift, home accessories, leather, cloth, hoolow cutting and etc.
Applicable Material
Suitable for wood products, paper, leather, cloth, plexiglass, epoxy, acrylic, wool, plastic, tubber, porcelain, crystal, jade, bamboo products and other non-metallic materials.
Technical parameters
Laser power |
80W/100W/150W |
Working area |
2500 *1300mm |
Max engraving speed |
60000mm/min |
Max cutting speed |
10000mm/min |
Laser output control |
1-100% software setting |
Location precision |
less than 0.01mm |
High scanning precision |
2500DPI |
Operating |
temperature: 0-45 degrees Celsius |
Operating humidity |
5-95% |
Min shaping character |
English 1.0 * 1.0mm, Chinese 2.0*2.0mm |
Supported format |
BMP, PLT, DST, DXF, and AI |
Driving system |
stepper |
Cooling mode |
water-cooling and protection system |
Auxiliary equipments |
Exhaust-fans, air-exhaust pipe, water pump |
Controlling software |
DSP control system. |
Compatible Software |
TAJIMA , CorelDraw, AutoCAD, Photoshop |
Wave length |
10.64um |
CE-Certification
Applications
1. Applicable Materials: Cloth, leather, paper, wood, organic glass, rubber, plastics, synthetic materials, etc.
2. Applicable Industries:Applies to clothing, fabric, leather, furniture, packaging, advertising, decoration, printing, construction, paper.
After-Sales Service & Warranty
1. We provide one year free warranty beyond which we charge only accessory fee and cost;
2. Warranties on laser tubes differentiate due to brands diversities. Contact us to get exact warranty period on your purchase;
1, Get warranty extension with preferential price;
2, Free lifetime remote technique-service via telephone, email, online video, Skype, QQ etc.;
3, Free lifetime training and guidance in our factory;
4, Get operating software CD, U Disc for free;
The following circumstances are exclusive
1, Natural aging of consumables and other parts;
2, Man-made damage due to maloperation against the operation manual;
3, Malfunction and damage caused by repair, transform without permission;
4, Damage caused by fire, flood, voltage anomaly and other force majeure;
5, Other non-product quality damage.
Why choose Aotopto?
About us - Dongguan Aotopto Technology Co., Ltd
AOTOPTO Technology Co., Ltd. is a professional manufacture focusing on providing solutions for medium and low power laser processing users. We combine R&D, produce and sales in vertical integration in laser value chain.
Based on the quality control system, the whole series of regular types has been certificated by European CE certification.
We promise we will provide products of better quality and our best service!
Exhibition in whole world
We have participated in many international exhibitions:
D.PES SIGN EXPO CHINA (GUANGZHOU)
International Textile &Clothing Industry Fair (DOGNGUAN),
International Footwear&MaterialIndustry Fair (DOGNGUAN),
International Advertising & Exhibition (Shanghai)
Munich Exposition in Germany, etc.
If you are distributor, Aotopto laserhopes to cooperate with you and participate in your local fair to help you to open and occupy the market.
Certification of Aotopto Machine (CE,FDA)
Aotopto laser machine have passed testing and comply with the international standard. With CE, our machines own a good market in Europe. There is no problem to export machine to America with FDA.
If you want import machine to Egypt or some countries with strict regulation, we can provide fumigation certificate.
FAQ
Q: What’s the function for Co2 laser?
A: CO2 Laser is used to engrave or cut almost all non-metal materials like acrylic, wood, paper, fabric, leather etc.
Q: How to choose among different models?
A: AZ/AZ-D Series: Sliding rail config. are mainly used for textile industry like fabric,textile,paper with faster speed
AZ-L Series: Square rail config.are mainly used for advertisement with higher precision for thick materials like acrylic, wood.
AZ-U Series: Up&down or rotary device is equipped for thick or cylindrical object on the base of standard series
AZ-H Series: Upgraded from D/L series, it’s equipped with square rail but larger working area
AZ-FH Series: On the base of AZ/AZ-D or H series, it’s suitable for both metal and non-metal.
Q: How about the package?
A: The machine will be wrapped with waterproof film and foam. We use strong seaworthy wooden box with fumigation to guaranty safe delivery.
Q: How about the delivery?
A: We have enough machines in stock. Exact delivery date is confirmed by actual order.
Q: Are you a factory or a trade company?
A: Yes, We are a factory.
Q: Where is your factory located? How can I visit there?
A: Our factory is located in Dongguan city, Guangdong province, China.
All our clients from home or abroad are warmly welcome to visit us!
Q: Do you have any certificates?
A: All series of machines have passed CE verification.
Q: What is the trade term?
A: FOB/CNF/CFR/CIF/EXW are favorable.
Q: What is the payment term?
A: We take 30% deposit and 70% balance should be paid before delivery by T/T.
West Union and PayPal are preferred for small amount.
Q: How can I get the documents after shipment?
A: All original documents will be sent to the client by DHL after shipping, including packing list, commercial invoice, B/L, and other certificates as required.
Q: Do you arrange shipment for the machines?
A: We will arrange shipment for transactions based on FOB/CIF terms.
For EXW price, shipment should be made by clients or their agents.
Any other questions will be replied as we receive your consult.
