Help CenterLaser Cutting Machine Lens With High Focal Power
Related Products
-
CW 3000/5000/5200 Industrial Automatic Water Cooling ChillerUS$ 1 - 600MOQ: 1 Piece -
CO2 Laser Machine Chiller CW5000/5200US$ 400 - 500MOQ: 1 Set
-
2016 Newest 150W Reci Laser Tube for Laser MachineUS$ 1 - 1,000MOQ: 1 Set
-
Co2 Laser Tube 80W CNC Laser Cutting Engraving MachineUS$ 1 - 1,000MOQ: 1 Set
-
Co2 Laser Tube 100w CNC Laser MachineUS$ 1 - 1,000MOQ: 1 Set
Co2 laser lens
Laser focus lens
Ordinal |
Type |
Diameter |
Focal length |
Thickness |
Materials |
01 |
D12.7ET2FL2 |
12.7 |
50.8 |
1.8 |
Zn Se/Ca As |
02 |
D14.5ET2FL1.5 |
14.5 |
38.1 |
1.8 |
Zn Se/Ca As |
03 |
D14.5ET2FL2.0 |
14.5 |
50.8 |
1.8 |
Zn Se/Ca As |
04 |
D15.26ET2FL1.5 |
15.26 |
38.1 |
2.0 |
Zn Se/Ca As |
05 |
D15.26ET2FL2.0 |
15.26 |
50.8 |
2.0 |
CVD/PVD Zn Se |
06 |
D15.26ET2FL2.5 |
15.26 |
63.5 |
2.0 |
CVD/PVD Zn Se |
07 |
D18ET2FL1.5 |
18.0 |
38.1 |
2.0 |
CVD /PVD Zn Se |
08 |
D18ET2FL2.0 |
18.0 |
50.8 |
2.0 |
CVD /PVD Zn Se |
09 |
D18ET2FL2.5 |
18.0 |
63.5 |
2.0 |
CVD /PVD Zn Se |
10 |
D18ET2FL3.0 |
18.0 |
76.2 |
2.0 |
CVD /PVD Zn Se |
11 |
D18ET2FL4.0 |
18.0 |
101.6 |
2.0 |
CVD /PVD Zn Se |
12 |
D20ET2FL1.5 |
20.0 |
38.1 |
2.0 |
CVD /PVD Zn Se |
13 |
D20ET2FL2.0 |
20.0 |
50.8 |
2.0 |
CVD /PVD Zn Se |
14 |
D20ET2FL2.5 |
20.0 |
63.5 |
2.0 |
CVD /PVD Zn Se |
15 |
D20ET2FL3.0 |
20.0 |
76.2 |
2.0 |
CVD /PVD Zn Se |
16 |
D20ET2FL4.0 |
20.0 |
101.6 |
2.0 |
CVD /PVD Zn Se |
17 |
D19.05ET2FL1.5 |
19.05 |
38.1 |
2.0 |
CVD /PVD Zn Se |
18 |
D19.05ET2FL2.0 |
19.05 |
50.8 |
2.0 |
CVD /PVD Zn Se |
19 |
D19.05ET2FL2.5 |
19.05 |
63.5 |
2.0 |
CVD /PVD Zn Se |
20 |
D19.05ET2FL3.0 |
19.05 |
76.2 |
2.0 |
CVD /PVD Zn Se |
21 |
D19.05ET2FL4.0 |
19.05 |
101.6 |
2.0 |
CVD /PVD Zn Se |
22 |
D25.4ET3FL50.8 |
25.4 |
50.8 |
3.0 |
CVD Zn Se |
23 |
D25.4ET3FL63.5 |
25.4 |
63.5 |
3.0 |
CVD Zn Se |
24 |
D25.4ET3FL76.2 |
25.4 |
76.2 |
3.0 |
CVD Zn Se |
25 |
D25.4ET3FL101.6 |
25.4 |
101.6 |
3.0 |
CVD Zn Se |
26 |
D25.4ET3FL127 |
25.4 |
127 |
3.0 |
CVD Zn Se |
27 |
D27.94ET3FL50.8 |
27.94 |
50.8 |
3.0 |
CVD Zn Se |
28 |
D27.94ET3FL63.5 |
27.94 |
63.5 |
3.0 |
CVD Zn Se |
29 |
D27.94ET3FL76.2 |
27.94 |
76.2 |
3.0 |
CVD Zn Se |
30 |
D27.94ET3FL101.6 |
27.94 |
101.6 |
3.0 |
CVD Zn Se |
31 |
D27.94ET3FL127 |
27.94 |
127 |
3.0 |
CVD Zn Se |
32 |
D30ET3FL50.8 |
30.0 |
50.8 |
3.0 |
CVD Zn Se |
33 |
D30ET3FL63.5 |
30.0 |
63.5 |
3.0 |
CVD Zn Se |
34 |
BL30ET3FL76.2 |
30.0 |
76.2 |
3.0 |
CVD Zn Se |
35 |
BL30ET3FL101.6 |
30.0 |
101.6 |
3.0 |
CVD Zn Se |
36 |
D30ET3FL127 |
30.0 |
127 |
3.0 |
CVD Zn Se |
37 |
D38.1ET2FL5 |
38.1 |
127 |
7.87 |
CVD Zn Se |
38 |
D38.1ET2FL7.5 |
38.1 |
190.5 |
7.87 |
CVD Zn Se |
Description
1. The laser focus lens are all made of the United States imported CVD zinc selenide, material absorption rate is low, the production of lenses can withstand the high power density, and surface film layer and firm, not easy to fall off, resistance to wipe. Import zinc selenide double plating coating its main function is to reduce or eliminate on the surface of the optical lens, prism, flat mirror reflected light, which increase the amount of these components of pervious to light, reduce or eliminate the stray light of system.
2.As the widely used to expand, forming a coating of various requirements, such as: single wavelength anti-reflection film, broadband antireflection film , ultra broadband antireflection film, dual-band anti-reflection coating, double wavelength, etc.Commonly used in CO2 laser industry working band of 10.6 mu m transmittance can reach 99.8%.
3. As the most economical transmission is focused on the element, the lens is suitable for laser heat treatment, welding, cutting and infrared radiation, in order to obtain satisfactory performance,Should be toward the collimating lens surface of the incident beam, or toward the conjugate distance (distance and the like from being known as the conjugate distance).
Cleaning method
- When operated by hand to the optical system, regardless of the cleaning, disassembly, install all want to wear gloves or medical gloves, always keep follow the requirements and matters needing attention of cleaning lenses.
- In the process of cleaning, use only materials, such as optical lens wiping paper, cotton swabs, reagent grade ethanol and high purity of alcohol for any lens cleaning, disassembly, install shortcuts will lead to laser lens life expectancy, even permanent damage.
- Pollution in determining a laser lens, we need to wash the ears ball lens, until the surface no particles to be beautiful, don't use mouth to blow. Because the air blow out mostly oil and water will be further pollution lens.
- If after washing ears ball handling its surface pollution still exist, we will have to dip in with cotton swabs for laboratory grade acetone, ethanol, alcohol to wipe gently. So you can remove most of the thin layer of pollution.
- Laser lens pollution in the will of the laser output and data sampling system pose a serious mistake, if we can make the lens keep clean, often will can prolong the service life of the machine.
Why choose Aotopto?
About us - Dongguan Aotopto Technology Co., Ltd
AOTOPTO Technology Co., Ltd. is a professional manufacture focusing on providing solutions for medium and low power laser processing users. We combine R&D, produce and sales in vertical integration in laser value chain.
Based on the quality control system, the whole series of regular types has been certificated by European CE certification.
We promise we will provide products of better quality and our best service!
Exhibition in whole world
We have participated in many international exhibitions:
D.PES SIGN EXPO CHINA (GUANGZHOU)
International Textile &Clothing Industry Fair (DOGNGUAN),
International Footwear&MaterialIndustry Fair (DOGNGUAN),
International Advertising & Exhibition (Shanghai)
Munich Exposition in Germany, etc.
If you are distributor, Aotopto laserhopes to cooperate with you and participate in your local fair to help you to open and occupy the market.
Certification of Aotopto Machine (CE,FDA)
Aotopto laser machine have passed testing and comply with the international standard. With CE, our machines own a good market in Europe. There is no problem to export machine to America with FDA.
If you want import machine to Egypt or some countries with strict regulation, we can provide fumigation certificate.
1, We provide one year free warranty beyond which we charge only accessory fee and cost;
2, Warranties on laser tubes differentiate due to brands diversities. Contact us to get exact warranty period on your purchase;
3, Get warranty extension with preferential price;
4, Free lifetime remote technique-service via telephone, email, online video, Skype, QQ etc.;
5, Free lifetime training and guidance in our factory;
6, Get operating software CD, U-Disc for free;
The following circumstances are exclusive:
1, Natural aging of consumables and other parts;
2, Man-made damage due to maloperation against the operation manual;
3, Malfunction and damage caused by repair, transform without permission;
4, Damage caused by fire, flood, voltage anomaly and other force majeure;
5, Other non-product quality damage.
Contact us to obtain quick response and excellent service!
