5 Ton Tow Truck/Road Wrecker

US$ 45,000 - 60,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Horsepower:

150 - 250hp

Drive Wheel:

4x2

Shanghai Junling Industry Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Many port in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Horsepower 150 - 250hp

Drive Wheel 4x2

Transmission Type Manual

Emission Standard Euro 4

Fuel Type Diesel

Brand Name QL

Size 6020x2170x2565

Gross Vehicle Weight 10000

Product Description

1. Wrecker and tow truck Specification

Items		Unit	Value
Boom Structure	Rated towing weight	kg	10000
	Max. Rated lifting weight	kg	2000
	Lifting weight of full extension boom	kg	800
	Effective length of boom	mm	1750
	Extension traveling of boom	mm	470
	Folding angle of boom	°	90
Under lift Structure	Rated hanging weight	kg	3000
	The height from hook to the ground	mm	4146
	Extension traveling of the lifting boom	mm	1400
	Numbers of winch	piece	1
	Max. Rated pulling power of winch	kg	4000
	Diameter of steel cable	mm	10
	Length of steel cable	m	25
	Min. Speed of steel cable	m/min	4.5
	Rotation angle	°	38
Vehicle Parameters	External dimension	mm	6020×2170×2565
	Axle base	mm	3815
	Drive		4×2
	The whole weight of empty load	kg	5060
	Load of front axle of empty load	kg	2435
	Load of rear axle of empty load	kg	2625
	The whole weight of full load	kg	9390
	Load of front axle of full load	kg	3150
	Load of rear axle of full load	kg	6240
	Wheel base (front/rear axle)	mm	1680/1650
	Front suspension	mm	1110
	Rear suspension	mm	900
	Approach angle	º	21
	Departure angle	º	18
	Min. Turning diameter	m	≤15
	Max. Speed	km/h	95
	Grade ability	%	30
	Min. Ground clearance	mm	215
	Engine model	-	4HK1-TC
	Engine emission	L	5.193
	Rated power	kw/r/min	129/2600
	Max. Torque	n·m/r/min	500/1500~2000
	Fuel type		Diesel
	Standard of emission		EN III
	Tire size		8.25R16(optional 8.25-16,8.25-20,8.25R20))
	Persons		3
