UD TRUCK (From Volvo group)
1.Cargo truck Specification
Basic information | Product name | Cargo rigid |
Type | 6×4 | |
Length x Width x Height(mm) | 11304×2499×3228 | |
Wheelbase(mm) | 5600+1370 | |
Front overhang/Rear overhang(mm) | 1460/2874 | |
Top speed(km/h) | 117 | |
GVW(kg) | 25000 | |
Rated load(kg) | - | |
Kerb Weight(kg) | 9450 | |
Approach/Departure angle(°) | 15/9 | |
Cab | Type | Cab-over-engine, Std. roof , single bunk |
Passengers(person) | 3 | |
Engine | Model | GH1A |
Manufacturer | UD Trucks Corporation | |
Displacement(L) | 10.837 | |
Emission | CN4 | |
Type | Inline 6 cylinders, 4 valves, hydro-cooling, turbo with inter-cooling | |
Power rating(kw) | 280 | |
Max net power(kw) | 279 | |
Injection technology | Electric unit injector with max injection pressure 200MPa | |
After treatment | SCR | |
Clutch | Type | Single disc, dry, pull-type diaphragm clutch |
Disc diameter(mm) | 420 | |
Gearbox | Model | F9R20A |
Type | Mechanical, manual, 12 forward gears + 2 reverse gears | |
Steering gearbox | Type | Recirculating ball type hydraulic power-assisted steering system |
Axle | Load capacity(kg) | Front: 8000/ Rear:26000(tandem) |
Rear axle ratio | 4.111 | |
Frame | Type | One piece by roll forming |
Max section area(mm) | 300×90×(8+5) | |
Suspension | Type | Front parabolic leaf, Rear multi leaf + T-ride, Front/Rear stabilizer |
Leaf Qty. | 3/11 | |
Tyre | Specification(either one) | 12.00R20-14PR |
315/80R22.5-16PR | ||
295/80R22.5-16PR |
2. Cargo truck Introduction
| Cargo truck Multi view angle mirrorConsiderately designed Mirror combination ensures full view for the driver; electrical-heated mirror as optional effectively improves driving safety in severe weather.
|
Cargo truck Front/Rear stabilizerEU desig concept for higher driving safty
|
Cargo truck Axle&Hub reduction axle&Single reduction axleHigh quality VOLVO designed axle with option of hub reduction for severe duty cycle |
Packaging & Shipping
1) Bulk ship and RORO ship
2)Container
1) Products Transportation
Our driver is professional trained to provide safe and fast transportation of Cargo trucks.
2) Customer clearance
Our team can provide customer clearance for all the Cargo trucks
3) Container Loading and fixing
Our company are professional exportor of all kinds of Cargo trucks, pickups and parts.
