Nissan UD quester 6x4 heavy cargo truck for sale (Volvo group)
- 30 Unit / Units per Month
- Shanghai
- T/T D/P D/A
- Nissan 25ton UD quester 6x4 heavy food cargo truck for sale (Volvo group)
- 6x4 GQ HINO tractor truck/prime mover for sale
- 6x4 2014 model heavy tow truck / tractor truck for sale with discount
- EXR, EXZ 4X2 and 6x4 tow truck/ tractor truck for sale
- 6x4 heavy duty truck tractor truck for sale/used tow truck/tow truck chains
- UD quester 6x4 heavy duty tractor truck payload 50ton dimension for sale
Product Details
Condition: | New | Capacity (Load): | 21 - 30t | Drive Wheel: | 6x4 |
Horsepower: | 351 - 450hp | Transmission Type: | Manual | Emission Standard: | Euro 4 |
Fuel Type: | Diesel | Size: | 10304x2499x3228 | ||
Gross Vehicle Weight: | 25000 | Place of Origin: | Zhejiang, China | Brand Name: | UD |
Model Number: | UD cargo |
Packaging Details
Naked (roll to roll shipping, special container, bulk cargo)
Product Description
UD TRUCK
1.Cargo truck Specification
Basic information | Product name | Cargo rigid |
Type | 6×4 | |
Length x Width x Height(mm) | 10304×2499×3228 | |
Wheelbase(mm) | 4600+1370 | |
Front overhang/Rear overhang(mm) | 1460/2874 | |
Top speed(km/h) | 117 | |
GVW(kg) | 25000 | |
Rated load(kg) | - | |
Kerb Weight(kg) | 9410 | |
Approach/Departure angle(°) | 15/9 | |
Cab | Type | Cab-over-engine, Std. roof , single bunk |
Passengers(person) | 3 | |
Engine | Model | GH1A |
Manufacturer | UD Trucks Corporation | |
Displacement(L) | 10.837 | |
Emission | CN4 | |
Type | Inline 6 cylinders, 4 valves, hydro-cooling, turbo with inter-cooling | |
Power rating(kw) | 280 | |
Max net power(kw) | 279 | |
Injection technology | Electric unit injector with max injection pressure 200MPa | |
After treatment | SCR | |
Clutch | Type | Single disc, dry, pull-type diaphragm clutch |
Disc diameter(mm) | 420 | |
Gearbox | Model | F9R20A |
Type | Mechanical, manual, 12 forward gears + 2 reverse gears | |
Steering gearbox | Type | Recirculating ball type hydraulic power-assisted steering system |
Axle | Load capacity(kg) | Front: 8000/ Rear:26000(tandem) |
Rear axle ratio | 4.111 | |
Frame | Type | One piece by roll forming |
Max section area(mm) | 300×90×(8+5) | |
Suspension | Type | Front parabolic leaf, Rear multi leaf + T-ride, Front/Rear stabilizer |
Leaf Qty. | 3/11 | |
Tyre | Specification(either one) | 12.00R20-14PR |
315/80R22.5-16PR | ||
295/80R22.5-16PR |
2. Cargo truck Introduction
| Cargo truck Multi view angle mirrorConsiderately designed Mirror combination ensures full view for the driver; electrical-heated mirror as optional effectively improves driving safety in severe weather. |
Cargo truck Front/Rear stabilizerEU desig concept for higher driving safty
|
Cargo truck Axle&Hub reduction axle&Single reduction axleHigh quality VOLVO designed axle with option of hub reduction for severe duty cycle |
Cargo truck chassis Large cab tilting angleMaximum tilting angle is 58 degrees and engine mounting & dismounting can be done when cab is tilted by 45 degree |
Front lid designed for easy maintenanceClutch fluid reservoir,wind shield washer tank, air conditioner filter behind front lid for easy daily check |
Company Profile
Shanghai Junling Industry Development Co., Ltd. is a professional company on trading all kinds of truck and modified vehicle. Good reputation, high-quality products and good service make us become a professional supplier of heavy duty truck and related products.
We are one sale department set by CNHTC(China National Heavy Duty Truck Group Co., Ltd. ) in Shanghai, which is the No1 brand in China heavy duty truck industry. Company deals all chassis and modified products made by CNHTC. There are dump trucks, concrete mixer trucks, tractor trucks, special trucks and all kinds of modified vehicles, etc.. The relationship as the sale department of CNHTC enables us to give customers more benefits. We have whole vehicle and spare part engineer who have working experience for many years in CNHTC, and have profound either theory or practice understanding on whole vehicle and spare parts. And they can sincerely supply professional service for yourself only. International trade salesmen are all trained and worked for many years, who have abundant knowledge of trucks and circumspect service attitude for customers. We all try our best to supply the professional, detailed, personalized products and service.
Here we would like to thank Sweden truck manufacturer Volvo company's confidence in us, make us become a supplier of Volvo chassis and modified vehicle in east China, will deal all kinds of modified vehicles of Volvo and Renault brand.
We are exclusive export agent of Suzhou City JieDa Fire Vehicle Equipment Co., Ltd., responsible for all matters relating to their product's export. Suzhou JieDa Fire Vehicle Equipment Co., Ltd. is China's one of the largest manufacturers of fire vehicles, which produces and modifies all kinds of fire vehicles to meet high-end demand and technical parameters. The products include hydraulic platform fire engine, dry-powder fire-extinguishing vehicle, combined dry-power and foam fire-fighting truck, air supply fire engines, emergency rescue fire vehicle, lifting high jet fire trucks, airport fire engines, fire extinguishing foam tanker, fire extinguishing water tanker, command and communication fire vehicle and so on.
Believing we can supply you high quality truck products in your need.
