GUANGQI HINO 6X4 Concrete Mixer Truck for Sale

Name: GUANGQI HINO 6X4 Concrete Mixer Truck for Sale
Brand: GUANGQI HINO
SKU: 103523477
Availability: InStock

US$ 55,000 - 75,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Guangdong, China

Brand Name:

GUANGQI HINO

Shanghai Junling Industry Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Main port in Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Guangdong, China

Brand Name GUANGQI HINO

Model Number Concrete mixer truck

Weight 25000

Dimension(L*W*H) 9070X2500X3880mm

Power(W) 254kw

Certification ISO,CCC

Warranty 12 months or 30000km

After-sales Service Provided Engineers available to service machinery overseas

1.Concrete Mixer truck Specification

Product Name	HINO 8-10CBM concrete mixer truck
Main parameters	Overall size(LWH)	907025003880mm
	Gross weight	25000kg
	Rated capacity	10800kg
	Curb weight	14070kg
	Max.speed	90km/h
Chassis	Chassis Brand	HINO
	Chassis model	YC
	Drive type	6X4
	Fuel Type	Diesel
	Tire Specification	11.00-20,11.00R20
	Tire No.	10
	Wheelbase	3640+1410mm
	Gearbox	FAST 9 speed manual
Engine	Manufacturer	Shanghai HINO Engine
	Model	P11C-VK
	Horse Power	350HP
	Displacement/Power	10520ml/259kw
	Emission standard	Euro 3/Euro 4

System	Item	Reference Data
Parameters of mixing drum	agitation volume (m3)	8-10
	charging rate (m3/min)	≥2.8
	discharging rate (m3/min)	≥1.2
	residual rate (%)	≤0.5
	rotating speed of mixing drum (rpm)	0~17
Driving system	speed reducer	made in Italy by PMP
	hydraulic pump	made in Italy by PMP
	hydraulic motor	made in Italy by PMP
	radiator	made in China
Water supply	water tank volume (L)	400
Water supply	type of water supply	air pressure water supply
Control system	control mode	connecting rod control
structure features	1,mixing drum and mixer blade using special wear-resisting material Q345, mixing drum material thickness is 5mm,mixer blade material thickness is 4mm.
	2, material of blowpit and feed hopper scaleboard is just the same as the mixing drum;
	3,humanizing operating system,connecting rod operation,concise safe and reliable;
	4,using imported brand-name hydraulic system;
	5,flushing water back control;
	6,product with quick discharging, no residual
