Diesel Concrete Mixer Trucks Dimension Cheaper Than ISUZU

Name: Diesel Concrete Mixer Trucks Dimension Cheaper Than ISUZU
Brand: HOWO
SKU: 103523491
Availability: InStock

US$ 45,000 - 55,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

China

Brand Name:

HOWO

Shanghai Junling Industry Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Main port in Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin China

Brand Name HOWO

Model Number SINOTRUK

Weight 31000kg

Dimension(L*W*H) 10820x2496x3980

Power(W) 280kw

Certification CCC

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

1. HOWO Concrete mixer truck (From SINOTRUK group)

Vehicle Description
Type	Concrete Mixer Truck	Overall Dimensions(mm)	1082024963980
GVW(kg)	31000	Mass in working order(kg)	16550
Design Loading Weight(kg)	14320	Max speed(Km/h)	80
Chassis Description
Chassis Model	ZZ1317N3667D1L	Number of axles	4
Cab	SINOTRUK	Allowable Passengers In Cab	2
Wheel base(mm)	1800+3600+1350	F/R track base(mm)	2022/2022/1830/1830
F/R overhang(mm)	1500/2570	Approach/Departure angle(°)	19/24
Spring plate	4/4/12	F/R axle-load	6500/7000/17500
Tire specification	12.00-20	Tire quantity	12+1
Air conditioner	optional	Type of fuel	Diesel
Braking system	Air braking	Electric system	24V
Traction system	8*4	Operation control system	Steering Wheel
Engine Description
Engine model	T12.38-40	Engine manufacturer	China Sinotruk Group Co., LTD
Exhaust/output	11596	Horse power	380
Up-parts Description
Fact cubage(L)	6700
Special equipment	Hydraulic pump, hydraulic motor, reducer, radiator, water tank, etc
Production	15-20 days
Warranty	12 months or 30,000km
