2007 Year Used 6x4 Cement Mixer Truck For Sale With 9cbm Mixer

Name: 2007 Year Used 6x4 Cement Mixer Truck For Sale With 9cbm Mixer
Brand: isuzu
SKU: 103522533
Availability: InStock

US$ 35,000 - 70,000 MOQ: 1 Unit

Key Specifications

Condition:

Used

Year:

2007

Make:

CIMC

Shanghai Junling Industry Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Main port in Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition Used

Year 2007

Make CIMC

Place of Origin China

Brand Name isuzu

Model Number Concrete mixer truck

Weight 25000

Dimension(L*W*H) 8600x2490x3950 mm

Power(W) 254kw

Certification ISO,CCC

Warranty one year warranty,1 year

After-sales Service Provided Engineers available to service machinery overseas

1.Concrete Mixer truck Specification

Overall Specifications	Chassis model	Isuzu CYZ51K
	Curb weight	12900 kg	28439 lbs
	Gross vehicle weight	25000 kg	55155 lbs
	Dimensions(L×W×H)	8600×2490×3950 mm	28.21ft×8.17ft×12.96ft
	Wheelbase	3225mm+1310mm	10.58ft+4.30ft
	Minimal ground clearance	≥240 mm	9.45 in
	Max.speed	85 km/h	52.8 mph
	Max. Gradeability	37%	37%
	Min. turning diameter	13.6 m	44.62 ft
	Clutch	Pneumatic auxiliary hydraulic controller, attached with dry single disc of buffer spring, external diameter:430mm
	Gearbox	MJD7S 6 forward gears, overgear with lubricating oil cooler
	Drive mode	6×4
	Steering gear	Recirculation ball integral power booster
	Brake mode Travel brake	Fully pneumatic, dual-circuit, rolling cone(wedge-shaped), Leading trailing shoe act on forward and backward rear wheel, ABS(Anti-lock Brake System), ABA(Automatic-liner-gap Based Automatic-adjustment)
	Aux. brake	Exhaust braking system, electronic control butterfly valve is arranged in the exhaust pipe.
	Parking brake	Spring actuator act on rear wheel
	Tyre	295/80R22.5 RIBLUG(Front/Rear)
	Rim	8.25V×22.5 13t (ISO 10 threaded stud holes)
	Power-Take-Off(PTO)	588N.m/1100rpm	411.6lbf.ft/115.5 rad/s
	Rated crewmen	3 persons
Engine	Engine model	Isuzu 6WF1A
	Type	4 stroke, Water cooled direct-injection turbocharged centrally-mounted cooler, diesel engine, overhead camshaft, common rail system
	Bore×stroke	147mm×140mm	5.79in×5.51in
	Displacement	14.256L	869.9in3
	Rated power	265kw/1800rpm	360hp/189rad/s
	Max. Torque	1422N.m/1100rpm	1048.9lbf.ft/115.5 rad/s
	Emission Standard	Euro III
