4x2 30ton Hino Trailer Head Truck With Truck Trailer Dimension for Sale

Name: 4x2 30ton Hino Trailer Head Truck With Truck Trailer Dimension for Sale
Brand: Sinotruk
SKU: 103521329

US$ 15,000 - 25,000 MOQ: 1 Unit

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

Other, CCC ISO9001:2000

Shanghai Junling Industry Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Main port in China

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification Other, CCC ISO9001:2000

Size 13000mmx2500mmx1650mm

OEM No. NONE

Max Payload 30000kg

Place of Origin China

Brand Name Sinotruk

Model Number JL

Product Description

1. truck trailer Specification

Specifications
Manufacturer	Shandong Shengrun Automoblie Co., Ltd
Model Nunber	SKW9350TDP/SKW9402TDP
Tare Weight	About 8.5T-13T
Dimension	13000mm2500mm-3500mm1650mm (Size can be choose freely)
Loading Capacity	40T-100T
Axle	13T/16T, FUWA/BPW/Huajing Brand
Rim	8.5-20 13PCS or other sizes
Tire	12R20 13 PCS or other sizes ,Triangle/Double Coin
Suspension	Mechanical suspension (Germany Type or America Type) or Air suspension(China brand or BPW brand)
Spring leaf	90(W)mm13(Thickness)mm10 Layer (especial for exporting market )
King pin	JOST brand 2.0 or 3.5 inch bolts type or Welding type
Support leg	JOST brand D200T or China brand 28Tons (Double speed)
Main beam	Height: 450mm-520mm, upper plate is 14mm-25mm, middle plate is 8mm-12mm, down plate is 16mm-25mm ; Material is Q345B Steel .
Side beam	16mm-25mm channel steel ( Material is Q235steel ).
Bottom Platform	5mm thickness diamond steel plate or can be optional
Ladder	Manual type or Hydraulic type
Gooseneck	For choose
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; Two pieces of 45L air tanks
ABS	Optional
Valve	WABCO valve
Light	LED light (Special for export market)
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO or 40HQ container.
