Detail product Description:
| Product Photos | 68-PLCC_21-0049D |
|---|---|
| Product Training Modules | Migrating from 8/16-Bit MCUs to 32-Bit ARMs |
| PCN Obsolescence/ EOL | Multiple Devices 29/Dec/2014 |
| Standard Package | 18 |
| Category | Integrated Circuits (ICs) |
| Family | Embedded - Microcontrollers |
| Series | 80C |
| Packaging | Tube |
| Core Processor | 8051 |
| Core Size | 8-Bit |
| Speed | 24MHz |
| Connectivity | EBI/EMI, I²C, UART/USART |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 40 |
| Program Memory Size | - |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| RAM Size | 256 x 8 |
| Voltage - Supply (Vcc/Vdd) | 4.5 V ~ 5.5 V |
| Data Converters | A/D 8x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 68-LCC (J-Lead) |
| Supplier Device Package | 68-PLCC (24.23x24.23) |
| Online Catalog | 80C |
FEATURES
• 80C51 central processing unit
• 8k × 8 ROM expandable externally to 64 kbytes
• ROM code protection
• An additional 16-bit timer/counter coupled to four capture registers and three compare registers
• Two standard 16-bit timer/counters
• 256 × 8 RAM, expandable externally to 64 kbytes
• Capable of producing eight synchronized, timed outputs
• A 10-bit ADC with eight multiplexed analog inputs
• Two 8-bit resolution, pulse width modulation outputs
• Five 8-bit I/O ports plus one 8-bit input port shared with analog inputs
• I2C-bus serial I/O port with byte oriented master and slave functions
• Full-duplex UART compatible with the standard 80C51
• On-chip watchdog timer
• Three speed ranges:
– 3.5 to 16 MHz
– 3.5 to 24 MHz (ROM, ROMless only)
• Three operating ambient temperature ranges:
– P83C552xBx: 0 °C to +70 °C
– P83C552xFx: –40 °C to +85 °C
(XTAL frequency max. 24 MHz)
– P83C552xHx: –40 °C to +125 °C
(XTAL frequency max. 16 MHz)
