Poly 170W Solar Panels

US$ 0.59 - 0.88 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

NZX

Model Number:

NZX-170W/36V

Shenzhen Ningzexin Solar Electricity Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name NZX

Model Number NZX-170W/36V

Material Polycrystalline Silicon

Size 1580*808*40mm

Number of Cells 72PCS

Max. Power 170W

Specifications

Poly 170W Solar Panels
1,Certification:CE ,ISO 9000,ROHS
2,Power:170W/36V
3,High efficiency:17%

Poly 170W Solar Panels

ITEM NO.:	NZX-170W/36V
Solar Cell:	125*125 Poly
Maximum Power(W)	170w
Optimum Power Voltage(Vmp)	36.7
Optimum Operatige Current(Imp)	4.67
Open Circuit Voltage(Voc)	44.6
Short Circuit Current(Isc)	5.11
Nmber of Cell(pcs)	6*12
Size of Module(mm)	158080840
Front Glass Thikness(mm)	3.2
Maxium System Voltage (V)	1000
Temperature Coefficients of Isc(%)	+0.10
Temperature Coefficients of Voc(%)	-0.38
Temperature Coefficients of Pm(%)	0.047
Temperature Coefficients of Im(%)	+0.10
Temperature Coefficients of Vm(%)	-0.38
Temperature Range	-40°C to +85°C
Tolerance Wattage(e.g.+/-5%)	±5%
Surface Maximum Load Capacity	2400Pa
Allowable Hail Load	23m/s ,7.53g
Weight Per Piece(KG)	15
Cell Efficiency for 180W(%)	>17%
Frame(Material Corners,etc.)	Anodized Aluminum Alloy
Backing (Brand Type)	TPT
Warranty	3 years for the whole product, for the power,90% for 10 years, 80% for 25 years
Standard Test Conditions	AM1.5 1000W/ 25 +/-2°C
FF (%)	78.6%
