180W Mono Solar Panels
US$ 0.63 - 0.9
MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NZX
Model Number:
NZX-180W
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mono Solar Panel Price ListUS$ 0.65 - 0.9MOQ: 100 Pieces -
55W Mono Photovoltaic PanelsUS$ 45 - 70MOQ: 50 Pieces
-
High Quality Mono 6W 18V Solar Panel ManufacturerUS$ 1.16 - 1.8MOQ: 500 Pieces
-
2014 Chinese Solar Panels 250w PriceUS$ 0.65 - 0.88MOQ: 50 Pieces
-
Competitive Price Mono 20W Solar Panel SupplierUS$ 1.05 - 1.8MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
NZX
Model Number
NZX-180W
Material
Monocrystalline Silicon
Size
1580x808x35mm
Number of Cells
72pcs
Max. Power
180W
Specifications
180W Mono Solar Panels1)Efficiency: >17%
2) With Aluminum Alloy frame
3) With CE and RoHS approval
180W Mono Solar Panels
Detailed Product Description
| ITEM NO.: | NZX-180W/36 |
| Solar Cell: | 125*125Mono |
| Maximum Power(W) | 180W |
| Optimum Power Voltage(Vmp) | 38.2 |
| Optimum Operatige Current(Imp) | 4.74 |
| Open Circuit Voltage(Voc) | 44.6 |
| Short Circuit Current(Isc) | 5.23 |
| Nmber of Cell(pcs) | 6*12 |
| Size of Module(mm) | 1580*808*35 |
| Front Glass Thikness(mm) | 3.2 |
| Maxium System Voltage (V) | 1000 |
| Temperature Coefficients of Isc(%) | +0.10 |
| Temperature Coefficients of Voc(%) | -0.38 |
| Temperature Coefficients of Pm(%) | 0.047 |
| Temperature Coefficients of Im(%) | +0.10 |
| Temperature Coefficients of Vm(%) | -0.38 |
| Temperature Range | -40°C to +85°C |
| Tolerance Wattage(e.g.+/-5%) | ±5% |
| Surface Maximum Load Capacity | 2400Pa |
| Allowable Hail Load | 23m/s ,7.53g |
| Weight Per Piece(KG) | 15 |
| Cell Efficiency for 180W(%) | >17% |
| Frame(Material Corners,etc.) | Anodized Aluminum Alloy |
| Backing (Brand Type) | TPT |
| Warranty | 3 years for the whole product, for the power,90% for 10 years, 80% for 25 years |
| Standard Test Conditions | AM1.5 1000W/ 25 +/-2°C |
| FF (%) | 78% |
