VBW5A emery roller rice whitener

Specifications

1.VBW5A new rice machine
2.Combining the iron roller organic to emery roller,
3,Can easy to satisfy 5 t/h rice production li



Characteristics:

Traditional emery roller rice machine only have the function of grinding, but do not have function of friction , leading to increasing massive broken rice when processing, also increasing costs. While the traditional iron roller machine have the function of friction , the broken rice less when processing, but iron roller machine working principle decided the rice chaff is not easy to remove the surface of layer, influenced the appearance of the rice.

VBW5A is a new generation emery roller, its design based on concept of emery roller and iron roller machine integrated . The iron roller organic combine to emery roller, making rice to be grinded through emery roller at the same time iron roller rub the rice so as to have the same effection. Greatly reduce the processing time and cost.

Features:

1) the cabinet body, the big "memory".

Based on the Chinese market, VBW5A can easy to satisfy 5 t/h rice production line, and only three-quarters of the the ordinary emery roller rice machine, greatly reduce the volume space and cost.

2)compact structure , simple operation.

The whole machine is divided into feeding department, grinding department, the material department and absorb the chaff four parts and each of the part divided clearly.

3) "emery with iron".

Traditional rice machine only have single emery roller and iron roller or sand, iron roller of the simple model in series. But VBW5A have the new design concept, combining the iron roller organic to emery roller, making rice to be grinded through emery roller at the same time iron roller rub the rice so as to have the same effection.Greatly reduce the processing time and cost.

4) performance is remarkable

Join the VBW5A rice production line, the whole process of construction and other machining process: the broken rate by 10% to 30%, whitening rise 10 to 20%.





Main technical parameters:

Model	VBW5A
Capacity(t/h)	5
Motor power (kw)	45
Main rotry(r.p.m)	1000
Blower(m3/min)	30
Dimension(LxWxH)(mm)	1540*1790*1010

 Kindly, mail us for more information.

Please feel free to contact with me.

 Http://EZhou XingFang Grinding Tool CO.,Ltd

Add:No.6 Sihai Road Ezhou city Hubei Province

Tel:0711-3612448/3612103

Fax:0711-3612448/3612196



EZhou XingFang Grinding Tools Co., LTD. - FANGFANG brand emery roller for rice grinding - Original emery roller (grinding wheel) supporting manufacturers for Chinese rice mill machinery productive enterprise - National emery roller R&D center - It is also the standardization administration of emery roller industry.XingFang keeps to the quality guideline of innovation, refinement, in pursuit of number one, satisfying the customer for all time.

XingFang (The former EZhou FangFang Grinding Tools Co.,LTD.) is the biggest manufacturing base of emery roller and industrial grinding wheel in Hubei province,covering an area of 120,00 square meters,360 sets equipments, annual production capacity is 3,500 tons.We mainly manufactures emery roller, industrial rinding wheel two series.Industrial grinding wheel was sold to many famous enterprise, such as Wuhan Iron&Steel Group,Yegang Group,Ezhou Iron&steel Group, even sold to southwest regions of China. Control the domestic market occupancy rate at around 70% for years.

XINGFANG had the independent export right in June 2005. More than 290 models in 9 catalogues of products to satisfy different demands of customers, they have been sold throughout 29 provinces and autonomous regions and exported to more than 20 countries and regions such asThailand, Pakistan and Southeast Asia, widely loved by users.

"FANGFANG" brand had been continuously awarded four sessions "Brand Name Products of Hubei " since 1998. Especially emery roller,its unique productive process obtained patent on technology as well as the achveivement of technology in Hubei province for years. JM5 JM3, two types emery roller were awarded high-quality product of former Dep. of commerce in 1984.and won the silver of national quality product.

"Fangfang" brand emery roller consecutively passed the acceptance of the Hubei province high-quality goods brand before 2005.Has passed the ISO9001:2000 international standard certification and reexamination.
