PVC Profile Making Machine
Description:
PVC windows and doors profile, mostly it uses two model of extrusion lines, SJSZ65/132 extrusion line is special for production of main profile, like frame, sash, mullion, etc. and SJSZ51/105 extrusion line is special for production of small profile, such as glass bead, cap, connection, etc.
And this extrusion lines also can produce other shapes of PVC profile.
And if change to single screw extruder, the line can produce PE, PP, ABS profile
Technical parameter:
Model |
Product dimension (w×h)mm |
Extruder model |
output(kg/h) |
Max speed (m/min) |
Install power (kw) |
Main motor power(KW) |
Length of line(m) |
SJYF-180 |
180×60 |
SJSZ51/105 |
80-120 |
6 |
55 |
22 |
23 |
SJYF-240 |
240×120 |
SJSZ65/132 |
140-180 |
4 |
76 |
37 |
27 |
Main configuration:
Name |
Quantity |
Automatic loader |
1 set |
SJZ51, SJZ65 conical twin screw extruder |
1 set |
Mould and calibrating |
1 set |
Vacuum calibrating table |
1 set |
Haul off machine |
1 set |
Printer |
1 set |
Synchro cutter |
1 set |
Tipping stacker |
1 set |
Other necessary equipment:
Name |
Quantity |
SRL-Z or SRL-W type of hot/cooling mixer |
1 set |
crusher |
1 set |
Milling machine |
1 set |
Air compressor |
1 set |
Pictures of equipment:
