Home > Products > Plastic Auxiliary Equipment > BXL Series Cool-Water Unit
BXL Series Cool-Water Unit
- Shanghai
 - T/T

You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Techno | |
| Model Number | BXL Series |
Product Description
BXL Series Cool-Water Unit
Description:
Cool-Water Unit adopts imported full-closed compressor of high frequency and strong refrigerating capacity.The unit is mainly suitable for rapidly cooling plastic mould and injector fuel tank,it will shorten the cycling time of operation so as to raise productivity and improve plastic products quality.And it also serves as a necessary refrigerating device for computerized tomography machine(CT) in hospital,chemical reaction pool,precision instrument workshop and ect.This unit is of high automatization,compact structure,nice appearance,convenient operation and energy saving.
Main Technical Parameter:
| Model | Unit  | SML-2S  | SML-3S  | SML-4S  | SML-5S  | SML-6S  | SML-7S  | SML-8S  | SML-9S  | SML-10S  | SML-11S  | SML-12S  | SML-13S  | |
| Use power | 380V 3 50Hz  | |||||||||||||
| Refrigeration output | Kw  | 7  | 10.5  | 17.5  | 21  | 26  | 29  | 35  | 54  | 70  | 108  | 139  | 174  | |
Kcal/h  | 6048  | 9073  | 15120  | 18000  | 22682  | 24940  | 30100  | 46623  | 60483  | 93000  | 120000  | 150000  | ||
| Pressure | Equipped power | Hp  | 2  | 3  | 5  | 7  | 7.5  | 10  | 12  | 15  | 15  | 15 × 2  | 20 × 2  | 25 × 2  |
| Method | Fully-enclosed made by France Taikang  | America BRISTOL  | ||||||||||||
| Cold-producing medium | R22  | |||||||||||||
| Operation method | Japan RKC  | Computer PlC-Automation  | ||||||||||||
| Cold medium water | Evaporator model | Baffle heat exchanger imported from Sweden  | ||||||||||||
| Outlet temperature | °C    | 5(5-30°C)  | ||||||||||||
| Frozen water flow | m3/h  | 3.2  | 3.2  | 3.2  | 6.3  | 6.3  | 8  | 8  | 13  | 16  | 18  | 22  | 28  | |
| Inlet/outlet joint | mm   | 3/4"  | 1"  | 1"  | 5/4"  | 5/4"  | 3/2"  | 3/2"  | 3/2"  | 2"  | 5/2"  | 3"  | 3"  | |
| Cooling water | Condenser model | Baffle heat exchanger imported from Sweden  | ||||||||||||
| Outlet temperature | ≤36  | |||||||||||||
| Cooling water flow | m3/h  | 3  | 4  | 5  | 6  | 7  | 8  | 8  | 13  | 7.5  | 30  | 35  | 40  | |
| Inlet/outlet joint | mm   | 1/2"  | 3/4"  | 1"  | 1"  | 1"  | 1"  | 1"  | 1"  | 3/2"  | Flange DN50  | Flange DN65  | ||
| Safe protection device | High pressure,low pressure, water circuit breaker,anti-freezing,overload,lacking phrase,temperature protection for compressor  | |||||||||||||
| Appearance size (L × W × H) | mm  | 500×680 ×1300  | 1105×600×1400  | 1300×650 ×1450  | 1700×800 ×1200  | 2000×800×1700  | ||||||||
| Weight | kg  | 150  | 200  | 250  | 300  | 350  | 400  | 450  | 550  | 600  | 700  | 750  | 800  | |
Picture of Equipment:
