Help CenterRecycled Plastics Crusher
Related Products
Recycled Plastics Crusher
Description:
1.Plastic Crusher Machine has wide application and is used for crushing and recycling various plastic products and old materials.
2.Plastic Crusher adopts imported high-quality cutting-tool,that can be sharpened repeatedly,so it is specially durable.The installation of the cutting-tool can also be adjusted,it is convenient.
3.The rotation blade stand is a step design to make cutting force resolve and increase the cutting force multiplied.
4.The material of the rotation blade stand is T7A high-quality tool steel and it is reasonable hardness and softness.Besites,it is not easily broken or worn, it adopts high-strength steel screw (8. 8grade) to fix it. The structure is strong and durable.
5.The main body is Q235A thick-wall, high-quality steel,so it is hard to affect its mechanical performance after a long time using .
6.Combining separated design,the materials outlet door and filter of crushing chamber are easy for disassembling and cleaning.The feet are installed with slide wheels which are convenient moving.
Main Technical Parameter:
Model |
PC300 |
PC400 |
PC500 |
PC600 |
PC800 |
PC1000 |
Power |
5.5 |
7.5 |
11 |
15 |
22 |
30 |
Crushing Chamber(mm) |
Φ220x300 |
Φ246x400 |
Φ265x500 |
Φ280x600 |
Φ410x800 |
Φ500x1000 |
Rotary Blade |
9 |
12 |
15 |
18 |
24 |
34 |
Fixed Blade |
2 |
2 |
4 |
4 |
8 |
9 |
Capacity(kg/h) |
100-200 |
200-300 |
300-400 |
400-500 |
500-600 |
600-800 |
Screen Size(mm) |
Φ10 |
Φ10 |
Φ10 |
Φ10 |
Φ12 |
Φ14 |
Weight(kg) |
480 |
660 |
870 |
1010 |
1250 |
1600 |
Overall Dimension(mm) |
110x80x120 |
130x90x170 |
140x100x165 |
145x125x172 |
150x140x180 |
170x160x220 |
Picture of Equipment:
