Home > Products > Plastic Auxiliary Equipment > ZJF Series Plastic Powder Feeder
ZJF Series Plastic Powder Feeder
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Techno | |
| Model Number | ZJF Series |
Product Description
ZJF Series Plastic Powder Feeder
Description:
1.Plastic Powder Feeder also named Spring Feeder and it adopts spring screw conveying theory.
2.It can be used with all kinds of extruders.
3.It can carry plastic powder from storage tank to the hopper automatically through controlling feeding circle by material level.
4.It has a stable performance,saves your labour and realizes the safety and reliability.
Main Technical Parameter:
Model | ZJF100 | ZJF300 | ZJF700 |
Rated Conveying Capacity(kg/h) | 100 | 300 | 700 |
Hopper Capacity(kg) | 100 | 120 | 150 |
Spring Diameter(mm) | 30 | 36 | 58 |
Max Conveying Capacity(kg/h) | 200 | 450 | 1000 |
Feeding Tube and Spring Length(m) | 3 | 3-5 | 3-5 |
Storage Box Capacity(kg) | 120 | 150 | 200 |
Motor Power(kw) | 1.1 | 1.1 | 1.5 |
Dimension(mm) | 650x980 850x620x740 | 650x1162 905x655x840 | 820x1550 950x950x960 |
Weight(kg) | 120 | 150 | 250 |
Picture of Equipment:
