Help Center240HP Marine Diesel Engines
US$ 1,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
350HP Marine Diesel Engine InboardUS$ 1 - 9,999MOQ: 1 Set -
380HP Marine Diesel Engine Inboard EngineUS$ 1,000 - 50,000MOQ: 1 Set
-
540HP Inboard Diesel Engine Inboard EngineUS$ 1,000 - 50,000MOQ: 1 Set
-
550HP Marine Diesel Engine for ShipUS$ 1 - 50,000MOQ: 1 Set
-
510HP Boat Engine Marine Engine Inboard EngineUS$ 25000.00 - 25000.00MOQ: 1 Set
Condition
New
Engine
4 Stroke
Fuel Type
Diesel
Cylinders
6
Engine Position
Inboard
Dimensions (L x W x H) (mm)
1652X939X1262mm
1. Technical parameters marine engine diesel
| YC6M/6MK Series Technocial Parameters | ||||||
| Model | YC6M220C | YC6M240C | YC6M240C | YC6M260C | YC6M270C | YC6M295C |
| Type | Vertical in line water cooled four-stroke direct-injection | |||||
| Combustion chamber type | Direct injection | |||||
| Number of cylinders bore*stroke | 6*120*145mm | |||||
| Intake way | Turbo-charging | Turbo-charging & Inter-cooled | ||||
| Displacemen (L) | 9.839 Emission T2 | |||||
| Compression ratio | 17.5:1 | |||||
| Continuous Power/Speed (Kw/r/min) | 162(220)/1800 | 176(240)/1500 | 176(240)/1500 | 192(260)/1800 | 199(270)/1500 | 216(295)/1800 |
| One-hour Power/Speed (Kw/w/min) | 178(242)/1800 | 194(264)/1800 | 194(264)/1800 | 211(286)/1548 | 219(297)/1858 | 238(238)/1858 |
| Min.specific fuel consumption | ≤189(g/kw.h) | |||||
| Specific oil consumption | <0.5(g/kw.h) | |||||
| Rotation direction | counterclockwise | |||||
| Starting | Electric motor | |||||
| Net Mass (kg) | 1200 | |||||
| Overall dimensions (mm) | 1652*939*1262 | |||||
| Applicable alltitude | < 2500 | |||||
| Reduction gearbox to be matched | 300 J300 D300 | |||||
| Certificate | ZC ZY CCS IMO | |||||
| Model | YC6M280C | YC6M300C | YC6M320C | YC6MK300C | YC6MK320C | YC6MK330C |
| Type | Vertical in line water cooled four-stroke direct-injection | |||||
| Number of cylinders bore*stroke | 6*120*145mm | 6*123*145mm | ||||
| Intake way | Turbo-charging & Inter-cooling | |||||
| Displacement (L) | 9.84 | 10.338 | ||||
| Compression ratio | 17.5:1 | |||||
| Continuous Power/Speed (Kw/r/min) | 205(280)/2100 | 219(300)/1500 | 234(320)/2100 | 221(300)/1500 | 235(320)/1800 | 242(330)/1500 |
| One-hour Power/Speed (Kw/w/min) | 227(308)/2168 | 241(330)/1548 | 257(352)/2168 | 243(330)/1548 | 259(352)/1858 | 266(363)/1548 |
| Min.specific fuel consumption | ≤189(g/kw.h) | |||||
| Specific oil consumption | ≤0.5(g/kw.h) | |||||
| Oil Capability (L) | 28 | |||||
| Rotation direction | Counterclockwise | |||||
| Starting | Electric motor | |||||
| Net Mass (kg) | 1200 | |||||
| Overall dimensions (mm) | 1652*939*1262 | |||||
| Reduction gearbox to be matched | MB242, MB270, 300 etc | |||||
| Certificate | ZC ZY CCS IMO | |||||
2.Factory & Workshop & Service center
