550HP Marine Diesel Engine for Ship
US$ 1 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
510HP Boat Engine Marine Engine Inboard EngineUS$ 25000.00 - 25000.00MOQ: 1 Set -
400HP Marine Diesel Engine Inboard EngineUS$ 1 - 1,000MOQ: 1 Set
-
480HP Marine Diesel Engine InboardUS$ 1 - 1,000MOQ: 1 Set
-
Marine Diesel Engine Inboard EngineUS$ 1,000 - 50,000MOQ: 1 Set
-
730HP Marine Diesel Engine Inboard BoatUS$ 1 - 50,000MOQ: 1 Set
Condition
New
Engine
4 Stroke
Fuel Type
Diesel
Cylinders
6
Engine Position
Inboard
Dimensions (L x W x H) (mm)
1956X980X1100
Picture of engine:
Technical Parameters:
| Model | YC6TD550L-C20 | ||
| Type | 6-cylinder,Vertical in line,direct injection, water-cooled and 4-stroke | ||
| Number of cylinders*Bore*Stroke (mm) | 6*152*180 | ||
| Intake way | Turbocharged & intercooled | ||
| Displacement (L) | 19.59 | ||
| Compression ratio | 14:01 | ||
| Continuous power/speed (kw/r/min) | 405KW(550HP)/1500rmp | ||
| One Hour Power /Speed(g/KW.h) | 445.5KW(605HP)1548rmp | ||
| Min. specific fuel consumption (g/kw*h) | 195 | ||
| Specific oil consumption (g/kw*h) | ≤1 | ||
| Engine oil capacity (L) | 52 | ||
| Crankshaft rotation direction | Anticlockwise | ||
| Start method | Electric(Gas start is optional) | ||
| Net weight (kg) | 1940 | ||
| Overall dimention (L*W*H) (mm) | 1956*980*1100 | ||
| wooden packing dimension (L*W*H) (mm) | 2200*1100*1300 | ||
| Gross weight (KG) | 2200 | ||
| Matched reduction gearbox | 400 | ||
| Certificate | CCS IMO | ||
