450HP Marine Diesel Engine Inboard Engine

450HP Marine Diesel Engine Inboard Engine thumbnail-1
450HP Marine Diesel Engine Inboard Engine photo-1
US$ 1,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
1 - 2L
Contact Supplier Request Quote Chat Now
Guangxi Yulin Excellent Power Generator Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Confirm by Customer
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Engine Capacity 1 - 2L
Fuel Type Diesel
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 2072X1105X1644

1. YC6T540C Technology parameters     boat inboard engine





Model YC6T390C YC6T420C YC6T480C YC6T510C YC6T540C YC6T380C
Type 6 cylinders ,Vertical in line water cooled four-stroke direct-injection
Number of cylinders bore*stroke 6*145*165mm
Intake way Turbo and charge air cooled
Displacement             (L) 16.35
Compression ratio 15.5:1
Continuous Power/Speed (Kw/r/min) 287(390)/1800 309(420)/1800 352(480)/1800 375(510)/1800 396(540)/1800 279(380)/1200
One-hour Power/Speed   (Kw/w/min) 315(429)/1858 340(462)/1858 387(528)/1858 413(561)/1858 436(594)/1850 307(418)/1238
Min.specific fuel consumption  195(g/kw.h)
Specific oil consumption        <1.0(g/kw.h)
Oil Capability           (L)            52
Min.steady speed         (r/min) 700 540
Rotation direction counterclockwise
Starting Electric motor
Net Mass                 (kg) 1960
Overall dimensions       (mm) 1880*1000*1860
Reduction gearbox to be matched 300     J300     D300
Certificate ZC   ZY     CCS
Model YC6T375C YC6T400C YC6T410C YC6T450C YC6T300C YC6T350C
Type Vertical in line water cooled four-stroke direct-injection
Number of cylinders bore*stroke 6*145*165mm
Intake way Turbo and charge air cooled
Displacement             (L) 16.35
Compression ratio 15.5:1
Continuous Power/Speed (Kw/r/min) 276(375)/1500 294(400)/1500 300(410)/1500 330(450)1500 220(300)/1200 257(350)/1200
One-hour Power/Speed   (Kw/w/min) 304(413)/1548 323(440)/1548 330(451)/1548 363(495)/1548 242(330)/1238 283(385)/1238
Min.specific fuel consumption  195(g/kw.h)
Specific oil consumption        <1.0(g/kw.h)
Oil Capability           (L)            52
Min.steady speed         (r/min) 675 540 540
Rotation direction counterclockwise
Starting Electric motor
Net Mass                 (kg) 1960
Overall dimensions       (mm) 1880*1000*1860
Reduction gearbox to be matched 300, J300 D300
Certificate ZC   ZY     CCS

Yuchai marine engines include nine series, i.e.YC6C,YC6T,YC6M,YC6A,YC6B,YC6108,YC6105,YC4D and YC4F, with a power coverage
of 32 to 880KW featuring with lower fuel consumption,smaller vibration,lower noise,higher reliability and stronger power.
They are used as the ideal power for speedboats,cargo ships ,passenger ships and fishing vessels.
Yuchai diesel engine products for power generator & gensets include several series,such as YC6C,YC6T,YC6M,YC6A,YC6B,YC6J
YC6G,YC4D,YC4F which are the ideal matching power for gensets with capacity of 24-600KW
The fully new T series dieesel engine is designed by YuChai Machinery Co.Ltd. Itself to satisfy the need. of the marketFEV,
the famous engine technology corporation in German,comblined with the advanced designing ideal,technology and the experience
of Yuchai,it is developed reliably.This series diesel engine has characteristics such as wide power range,low emissions,low
BSFC, low noise,high reliability and universal applicability.
YC6T series marine diesel engine is redesigned based on the YC6M series vehicle diesel engine in light of operation require
ment and structure feature of the marine diesel engine.The reformed engine has the advantages such as high reliability,large
power output and good fuel economy.It becomes the ideal power for freight and passenger ship.



(1)AVL four valve technology, greatly increased in, exhaust circulation area, more uniform atomization, burning more fully

P pump, P mouth, the injection pressure higher, ability to work more strong, injector and combustion chamber reasonable matching, mixing, fuel atomization best quality

(2)Hall Seth/federal supercharger economic condition wide

(3)Greatly reduce mechanical loss more than 15%, pump gas loss more small, costs reduced

And compared with power engine, fuel consumption reduce 10-15%





 2.Production process



450HP marine diesel engine inboard engine
