32 Inch Floor Standing Video Advertising Signage Screen
Specifications
1.32' Multimedia LCD Screen Standing2.Can add network and touch screen
3.Support CF/SD card and USB drive
4.Easy updating
Main Functions of the LCD Advertising Player
(1). Support multi language, such as Chinese, English, Russian, Korean, French, German, Italian, Spanish etc., with OSD key-lock function. Some other European languages are under developing.
(2). Support break-point memory. If the power supply is cut off occasionally, the player will play from the break point next time.
(3). Support YPBPR, RGB output.
(4). Support 480I, 480P, 720P output. Larger LCDs support 1080P.
(5). Support automatic and circulatory playing of programs in the flash memory card.
(6). Support CF card, SD card, USB2.0 and mini USB.
(7). Support Time Display on the screen. With calendar, week, day, time mode, and 5 playing schedule timers. Programming play lists can be edited by users, and the list will be saved in Memory.
(8). Support automatic On/Off functions.
(9). Support JEPG and BMP format pictures. With 16 kinds of Fade-in&Fade-out ways on the screen.
(10). Support Rolling txt on the screen, with different content and timers.
(11). Support Logo Display on the screen.
(12). Support background audio and lyrics. Supported format: MP3, WMA, MP2, PCM, AC3.
(13). Support various of video programs. Supported format: MPG, AVI, MPEG1, MPEG2, MPEG3, MPEG4, DAT, VOB, ASF, MOV, DIVS, etc.
(14). Support horizontal and Vertical UI Function.
(15). Support Files auto-copying function via USB port.
(16). Support Remote Controller Function.
(17). Support CF Card password function.
(18). Support Touch Screen playing list. ( Under Touch screen function)
(19). Supports Sub-screen or small window play. ( Under Network function)
(20). Support picture playing against background music function.
(21). Support flash card memory capability from 1GB to 32GB.
(22). With locking system design, which can provide the flash memory cards from removing.
(23). With Build-in stereo speaker, rated power: 2 x 5W. Audio amplifier function is available. (Max. rated power: 2 x 50W)
(24). Power supply: AC 110V-240V,50/60HZ
(25). Various of fixing ways: Back bracket mount, roof fixing, VESA holes, etc.
Trading Tearms
- Any Samples are available.
- Payment: T/T, Western Union, Cash.
- Packing List: LCD ad player, keys, English manual, remote controller, spare parts.
- Delivery Time: Samples in 3 Working days, large orders in 7 to 15 working days.
- Warranty: 1 year. 2% spare parts.
Model No. US-AD320s
Panel 32″TFT-LCD (LED back-light)
Display area(mm)/mode 930(W)×523(H) 16:9
Maximum resolution 1920*1080
Display color 16.7M
Pixel Pitch(mm) 0.48(H)×0.48(V)
Brightness (nits) 450cd/m2
Contrast 1000:1
Visual angle 178°/178°
Response time 5ms
Life(hrs) >60,000(hrs)
Input and output
Composite video input Optional
Y,Pb,Pr/Y,Cb,Cr input Optional
S-video Optional
HDMI Optional
Composite video loop output Optional
L/R audio input Optional
L/R audio output Optional
Speaker 2×5W(9Ω)
Video
Color system PAL/NTSC/SECAM
Remote controller Special
Ads input interfaces
USB 1 ( For 3G Wi-Fi)
RJ45 Network Interface
CF 1 (Built-in 4G CF card)
OSD display( screen menu display)
Menu language Chinese/English( multiple language option)
Power
Power supply AC100~240V 50 /60 HZ
Maximum power consumption ≤220W
Standby power consumption <5W
Temperature
Working temperature 0°C~50°C
Storage temperature -20°C~60°C
Working humidity 85%
Storage humidity 85%
Appearance
Panel color/appearance White, black, customized
Panel material Metal case SPCC
Installation Wall-mounted or Floor-standing
Function
Video format MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
Audio format Wave/MP3/WMA/AAC
Image format JPEG/BMP/TIFF/PNG/GIF
Image resolution 480P/720P/1080P
Split screen display Editable
Running subtitle location, word size, color and backlight are editable
Application:
The splicing picture combination, can reach the advertising media to the pursuit of large screen . Widly use to Airport, Finacial ,Metro,shopping mall,supermarket,Public place,assembly room ,Enterprise,Goverment ect.
Stable performance for video monitor and production scheduling ensure apply to: Public security,Transportation, Electrical Power , Energy sources,coal mine, Military and so on.
Application case:
We provide servise:
1. Customized requirment is available , OEM&ODM are welcome.
2. Reasonable and satisfactory solutions Provided to you by our professional engineers and staffs .
3. Warranty: one year overall unit ( Non-artificial damage )
Certificate:
Office and Workshop:
Products show:
