Narrow Bezel 40 Inch LCD Video Wall

Specifications

40" LCD Video Wall
narrow bezel 22mm,brightness 700cd/m2
good quality, moderate price
widely used in many areas
good service

40" LCD Video Wall with narrrow bezel 22mm



Specifications
Model No.					US-LTI4000HM03
Panel size					40" Samsung DID LCD screen(with narrow bezel 22mm)
Aspect Ratio					16:9
Resolution					1920x1080
Color					8Bit,16.7M
Brightness (nits)					700cd/m2
Contrast					4000:1
Visual angle (H/V)					178°
Response time					<=6ms
Life(hrs)					>60,000(hrs)
Input and output
Composite Video Input					3(3xBNC)
YUV/YPbPR					1(3xBNC)
S-YC					1(2xBNC)
D-15 RGB Input(VGA)					1
HDMI					1
DVI					1
Audio Input					1
Composite Video Output					2(2xBNC)
Splite Screen					Support Picture in Picture(PIP/POP/PAP)
Power
Power supply					AC100V~240V
Maximum power consumption					250W
Standby power consumption					<=3W
Temperature
Working temperature					0°C~50°C
Working humidity					20%-80%
Appearance
Product dimension( W X H X D) mm - 40"					911.7X524.2X128
Acessory
Cable					Can supply different kinds of cable
Video Wall Controller(Built-in each screen)
Model No.	US-P816A
Input	CVBS	3*BNC inputs, support PAL/NTSC all formats, 2*BNC loop outputs
	VGA	1*D15 port, support SVGA/XGA/WXGA
	YPbPr/YCbCr	1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P,1080I, HDTV
	Y/C	2*BNC inputs, support PAL/NTSC all formats
Output	LVDS	Support signal or double LVDS output, and WUXGA (1920*1080) display
Operate  mode	Panel key operation(needs customization)
	Standard RS232 port( provide free control software)
	Infrared Remote Control Operation
Engineering software	Customized
Working temperature	0~70 °C
working humidity	5~95 %RH
AC voltage power supply	100-240V/50, 60Hz
power consumption	Max 300W,according to different screen models
Dimension	338×295×60(mm)
Weight	About 3.5KG
