Ultra Narrow Bezel 5.3mm 55" Lcd Video Wall LED Backlight

Name: Ultra Narrow Bezel 5.3mm 55" Lcd Video Wall LED Backlight
Brand: USER
SKU: 103448173
Availability: InStock

Negotiable MOQ: 4 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

USER

Model Number:

US-LTI550HN01

Shenzhen USER Special Display Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name USER

Model Number US-LTI550HN01

Type TFT

Application Indoor

Panel Size 55 inch

Max Resolution 1920x1080

Viewing Angle 178°

Pixel Pitch 0.63

Color 16.7M

Contrast Ratio 4000:1

Brightness 700cd/m2

Response Time 6ms

Input Voltage 250W

Specifications

55" lcd Video Wall
Narrow bezel 5.3mm,brightness 700nit
Good quality,moderate price,good service
Widely used
LED backlight

55" lcd Video Wall with super narrow bezel 5.3mm LED backlight

Specifications
Model No.			US-LTI550HN01
Panel size			55" DID LCD screen(with narrow bezel 5.3mm,with LED Backlight)
Aspect Ratio			16:9
Resolution			1920x1080
Color			8Bit,16.7M
Brightness (nits)			700cd/m2
Contrast			4000:1
Visual angle (H/V)			178°
Response time			<=6ms
Life(hrs)			>60,000(hrs)
Input and output
Composite Video Input/(AV)			3(3xBNC)
YUV/YPbPR			1(BNC×3)
S-(YC)			1(BNC×2)
D-15 RGB Input(VGA)			1
HDMI			1
DVI			1
AUDIO INPUT			1
Composite Video Output			2(BNC×2)
Split Screen			Support Picture in Picture(PIP/POP/PAP)
Power
Power supply			AC100V~240V
Maximum power consumption			250W
Standby power consumption			<=3W
Temperature
Working temperature			0°C~50°C
Working humidity			20%-80%
Appearance
Product dimension			1215.3mm(H) × 686.1mm(V)
Acessory
Cable			Can supply different kinds of cable
Video Wall Controller(Built-in each screen)
Model No.	US-P816A
Input	CVBS	3BNC inputs, support PAL/NTSC all formats, 2BNC loop outputs
	VGA	1*D15 port, support SVGA/XGA/WXGA
	YPbPr/YCbCr	1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P,1080I, HDTV
	Y/C	2*BNC inputs, support PAL/NTSC all formats
Output	LVDS	Support signal or double LVDS output, and WUXGA (1920*1080) display
Operate mode	Panel key operation(needs customization)
	Standard RS232 port( provide free control software)
	Infrared Remote Control Operation
Engineering software	Customized
Working temperature	0~70 °C
working humidity	5~95 %RH
AC voltage power supply	100-240V/50, 60Hz
power consumption	Max 300W,according to different screen models
Dimension	338×295×60(mm)
Weight	About 3.5KG
