Advertising Monitor
Specifications
Software function is stable and reliableWith functions of prevention for card theft
Widely applies to the bus, building etc
| Specification model | US-M1901GQ | |||||||||
| Panel size | 19″TFT-LCD | |||||||||
| Display area(mm)/mode | 379(W)×304(H) 4:3 | |||||||||
| Maximum resolution | 1280*1024 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.294(H)×0.294(V) | |||||||||
| Brightness (nits) | 450cd/m2 | |||||||||
| Contrast | 1000:1 | |||||||||
| Visual angle | 170°/170° | |||||||||
| Response time | 5ms | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | No | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | No | |||||||||
| S-video | No | |||||||||
| HDMI | No | |||||||||
| Composite video loop output | No | |||||||||
| L/R audio input | 1 ( RCA * 2) | |||||||||
| L/R audio output | 1 ( RCA * 2) | |||||||||
| Speaker | 2×5W(9Ω) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| Remote controller | Special | |||||||||
| Ads input interfaces | ||||||||||
| USB | 1 ( USB2.0 interface) | |||||||||
| SD | 1 (Compatible MMC/MS) | |||||||||
| CF | 1 | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multiple language option required) | |||||||||
| Power | ||||||||||
| Power supply | AC 100~240 V 50/60 HZ | |||||||||
| Maximum power consumption | <=50W | |||||||||
| Standby power consumption | <3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 85% | |||||||||
| Storage humidity | 85% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 400*327*66 (just for reference) | |||||||||
| Panel color/appearance | White, black, customized | |||||||||
| Panel material | Metal case SPCC | |||||||||
| Installation | wall-mounted | |||||||||
