55 inch network digital signage with competitive price indoor lcd display
USD $500 - $1,500
/ Set
1 Set(Min.Order)
- 520 Set / Sets per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
-
digital fire alarm installation module display, HTN segment display with blue led lcd panel
-
negative autoreclose circuit-breaker lcd display, segment module with blue led
-
charger negative character lcd display,white led ,battery segment small flexible display
-
character small charger lcd display ,custom battery display ,white led
-
segment positive temperature time clock lcd display,blue TN white backlight
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | USER | Model Number: | US-AD550LD |
| Type: | TFT |
Product Description
55 inch network digital signage with competitive price indoor lcd display
1 Apply the newest 4Gth digital multimedia professor technologies, have excellent visual effect
2. Ultra-high-fidelity sound, pleasant stereo sound
3. Ultrathin and ultra-light hardware case, delicate and beautiful
4. Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill!
5. Verity and complete software, stable and reliable
6. Have a lock, anti-theft functions
7. Widely used in the bus, building and lift room, supermarket, pubic places, train etc
| Specification model | US-AD550LD | |||||||||
| Panel size | 55″TFT-LCD | |||||||||
| Display area(mm)/mode | 16:9 | |||||||||
| Maximum resolution | 1920*1080 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.4845H)×0.4845 (V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 5000:1 | |||||||||
| Visual angle | H178º V178º | |||||||||
| Response time | 8ms | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 1 (BNC X 3) | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | 1 (BNC X 3) | |||||||||
| S-video | 1 (BNC X 2) | |||||||||
| HDMI | 1 | |||||||||
| Composite video loop output | 1 | |||||||||
| L/R audio input | 1 ( RCA * 2) | |||||||||
| L/R audio output | 1 ( RCA * 2) | |||||||||
| Speaker | 2×5W(8Ω) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| Remote controller | Special | |||||||||
| Ads input interfaces | ||||||||||
| USB | 1 ( USB2.0 interface) | |||||||||
| SD | 1 (Compatible MMC/MS) | |||||||||
| CF | 1 | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multiple language option required) | |||||||||
| Power | ||||||||||
| Power supply | AC100~240V 50 /60 HZ | |||||||||
| Maximum power consumption | ≤720W | |||||||||
| Standby power consumption | ≤23W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 85% | |||||||||
| Storage humidity | 85% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 1249.6×739.2×122.5 (just for reference) | |||||||||
| Panel color/appearance | White, black, customized | |||||||||
| Panel material | Metal case SPCC | |||||||||
| Installation | rack-mounted | |||||||||
| Payment terms | ||||||||||
| price | USD/pcs ( FOB shenzhen) | |||||||||
| Payment | TT / Western union | |||||||||
| Detailed functions | ||||||||||
| Video format | MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI | |||||||||
| Audio format | Wave/MP3/WMA/AAC | |||||||||
| Image format | JPEG/BMP/TIFF/PNG/GIF | |||||||||
| Image resolution | 480P/720P | |||||||||
| Play mode | Power on, single card auto loop play;classified files auto loop play; multi cards auto loop display etc | |||||||||
| Time | year/month/day/week/h/m/s, in the top right corner (open and close optional) | |||||||||
| Timing open & close | Per day 5 times, 7 days a week, free time | |||||||||
| Timing play | 7 days a week, free set the play program everyday | |||||||||
| Alarm clock | Set 5 alarms one day, once ring the alarm, play the specified program | |||||||||
| OTG | Support copy, delete, remove, rename, build new file among different cards | |||||||||
| Running subtitle | Can set the play location, word size, color and back-color | |||||||||
| Log files | Record the play time (concise to second), the play contents | |||||||||
| Angle subscript display function | Can set the play time, just support BMP picture with biggest resolution 160*90 | |||||||||
| Memory function | Power off, memory the time of the play; power on, play from the time, not from beginning | |||||||||
| Key and lock function | Use the remote controller before input the keyword | |||||||||
| Encrypt CF card | Play the contents in the CF card before input the keyword | |||||||||
| Sound volume | Can set the volume of sound in the different time | |||||||||
| Storage card lock | Have a anti-theft lock in the case, equip 2 sets key | |||||||||
| Other function | Customized | |||||||||
| Upgrade software | Just put the upgrade file in the storage cards | |||||||||
