15 Inch Rack Mounted Industrial Lcd Monitor
US$ 1 - 300
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
USER
Model Number:
US-I1501R
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
19'' Square Touchscreen LCD MonitorNegotiableMOQ: 1 Piece -
19'' Touch Screen TFT Lcd MonitorUS$ 100 - 900MOQ: 10 Pieces
-
15'' Touch Screen MonitorUS$ 100 - 900MOQ: 3 Pieces
-
15" Touch Screen Monitor With Affordable PriceUS$ 200 - 300MOQ: 50 Pieces
-
42 Inch Touch Screen Monitor Iphone DesignUS$ 1,000 - 2,500MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
USER
Model Number
US-I1501R
Specifications
15 inch rack mounted industrial lcd monitorDisplay area(mm):304(W)*228(H) 4:3
Max resolution:1024*768
15 inch rack mounted industrial lcd monitor
| Specification model | US-I1501R | |||||||||
| Panel size | 8.4"TFT-LCD | |||||||||
| Display area(mm)/mode | 166(W)*125.5(H) 4:3 | |||||||||
| Maximum resolution | 1024*768 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.297(H)*0.297(V) | |||||||||
| Brightness (nits) | 350cd/m2 | |||||||||
| Contrast | 500:1 | |||||||||
| Visual angle | 140°/150° | |||||||||
| Response time | 8ms | |||||||||
| Horizontal frequency | 30-48KHZ | |||||||||
| Vertical frequency | 50-70Hz | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Installation | Rack-mounted | |||||||||
| Input and output | ||||||||||
| Composite video input | 1(BNC*1) | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | optional | |||||||||
| S-video | No | |||||||||
| D-15 pin RGB input | 1 | |||||||||
| DVI/HDMI (optional) | optional | |||||||||
| Composite video output | optional | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multi language supported) | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <=15W | |||||||||
| Standby power consumption | <1W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0 ~ 50 | |||||||||
| Storage temperature | -10 ~ 60 | |||||||||
| Working humidity | 20%~85% | |||||||||
| Storage humidity | 5%~95% | |||||||||
| Appearance | ||||||||||
| Body dimension(L*W*H)mm | 482*355*61.5 | |||||||||
| Panel material | metal case | |||||||||
