15'' Industrial Lcd Monitor
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
user
Model Number:
us-i1501e
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
user
Model Number
us-i1501e
product features:
Adopt industrial LCD screen, suitable for use in harsh environments.
Using durable components to maintain the stability of uninterrupted work
| Specification model | US-I1501E | |||||||||
| Panel size | 15″TFT-LCD | |||||||||
| Display area(mm)/mode | 304(W)×228(H) 4:3 | |||||||||
| Maximum resolution | 1024×768 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.297(H)×0.297(V) | |||||||||
| Brightness (nits) | 250cd/m2 | |||||||||
| Contrast | 500:1 | |||||||||
| Visual angle | 160°/160° | |||||||||
| Response time | 8ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Installation | Embedded | |||||||||
| Input and output | ||||||||||
| Composite video input | 2(BNC×2) | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | 1 (BNC×3) | |||||||||
| S-video | optional | |||||||||
| D-15 pin RGB input | 1 | |||||||||
| DVI/HDMI (optional) | 1 | |||||||||
| Composite video output | optional | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multiple language option required) | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | >=25W | |||||||||
| Standby power consumption | <W | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 482x355x61.5 | |||||||||
| Panel material | metal case | |||||||||
