24" CCTV LCD Monitor with Brightness of 500 Nits
USD $1 - $7,000
/ Set
2 Sets(Min.Order)
- 2000 Set / Sets per Month
- Shenzhen
- T/T Credit Card
You May Like
-
19" CCTV LCD Monitor with 500 Nits Brightness
-
17" CCTV LCD Monitor with Brightness of 500 Nits
-
rack mount lcd monitor,display lcd,cheap lcd monitor in 47inch with UL certificates
-
Display lcd,Rack mount lcd monitor,cheap lcd monitor in 42inch with UL certificates
-
12.1 inch cctv lcd monitor
-
8 inch CCTV LCD monitor
Product Details
| Place of Origin | Guangdong, China | Brand Name | USER | |
| Model Number | US-M2401P |
Product Description
Specifications
1. 24" CCTV lcd monitor2. CE, FCC,RoHS,UL certified
3. BNC,VGA,DVI,HDMI,YPbPr
4. Good quality
5. For cctv monitoring
Security field 24" cctv lcd monitor
| Specifications | ||||||||||
| Model No. | US-M2401P | |||||||||
| Panel size | 24" TFT-LCD | |||||||||
| Display area(mm)/mode | 522(W)×294(H) 16:10 | |||||||||
| Maximum resolution | 1920×1200 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.270(H)×0.270(V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 1200:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 31-60KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | 60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 3 (BNC×3) | |||||||||
| YPbPrinput | 1 (BNC×3) | |||||||||
| S-video | 2 (BNCX2) | |||||||||
| VGA | 1 | |||||||||
| HDMI | 1 | |||||||||
| DVI | 1 | |||||||||
| Composite video output | 2 (BNC×2) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| Compatible HDMI/DVI input | 480P,576P,720P,1080I,1080P | |||||||||
| 3D Comb filter | Yes | |||||||||
| Video reduction noise | Yes | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | 65W | |||||||||
| Standby power consumption | 3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 10%~90% | |||||||||
| Storage humidity | 10%~90% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 549.8x367×95mm | |||||||||
| Panel color/appearance | White,black,customized | |||||||||
| Case Material | Metal | |||||||||
| Net weight | 10kg | |||||||||
| Installation | Wall-mounted | |||||||||
