WC67Y-125/6000MM Hydraulic Press Brake Machine for Iron Palte

WC67Y-125/6000MM Hydraulic Press Brake Machine for Iron Palte thumbnail-1
WC67Y-125/6000MM Hydraulic Press Brake Machine for Iron Palte photo-1
US$ 70,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
SC
Contact Supplier Request Quote Chat Now
Wuxi Shengchong International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name SC
Model Number WE67K-300/4000
Machine Type Press Brake
Raw Material Sheet / Plate Rolling
Material / Metal Processed Carbon Steel
Power Hydraulic
Automation Automatic
Extra Services Machining
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Product Description
Equipment name WC67Y-125/6000MM Hydraulic press brake machine for iron palte

SHENCHONG Quality Pressbrakes feature high durability, and provide precision bending capabilities. The Pressbrake main frames are constructed from rolled, stress relieved solid steel to prevent distortion during the bending process and under extreme continuous loads.
SHENCHONG Pressbrakes are produced in a high volume production process and therefore are able to be manufactured cost effectively, resulting in affordable price, representing value for money and quicker return on investment.
Featuring an adjustable synchronised torsion bar with positive stop system ensures consistent and accurate bending beam parallelism tolerance to 0.01mm via the digital Control unit.
All electrical components are off European quality supplied by, Telemecanique, Merlin Gerin and ABB. Hydraulic control units are supplied by Aron from Italy.



Main feature
  • Hydraulic / Mechanical ram, synchronised positive stop design, ram stroke controlled by precision mechanical nut depth stops built into each cylinder.
  • Parallelism is ensured by torsion bar that can be easily adjusted by clutch system.
  • Segmented heavy duty 86° offset top punch is segmented for return bend clearance, complete with European style quick release punch holder with an adjustable wedge clamping system for crowning.
  • Intermediate clamp has safety key to stop punch dropping.
  • Multi vee ('V') bottom die is made from one 3200mm solid die block design to handle heavy plate, safety edge vee ('V') is incorporated in bottom die block.
  • Conveniently mounted control box on pendant for quick swivel and adjustments.
  • Mono-block steel frame design, welded then machined to ensure minimal bed deflection under load
  • Enclosed rear gate with micro safety switches complete with sliding rear door for easy access.
  • European quick release style top punch and clamping system, allowing operator to change position of tooling to suit multiple requirements on complex applications. This feature ensures minimum down time, more productivity and results in reduced cost per finished product.
  • Sliding steel fabricated sheet supports enabling a wide range of material sizes to be aligned and supported at the correct required height. This feature is achieved with a "T" slot machined down the total length of the die bed, sheet supports are also adjustable vertically to assist in supporting material with return bends already folded.
  • Adjustable sliding blocks control the machines beam to provide desirable open height distance to the (slow speed) mute bending point.
  • Operator adjustable locking knobs for quick adjustment, enables accurate repeatability and increased productivity.
  • Metal safety guarding surrounding the machine with rear sliding door fitted and micro switch ensuring operator safety.
  • Clear access panels placed at each end of machine allows the operator to clearly view tooling and work piece during bending operation. SHENCHONG specially design gates to suit Australian safety requirements.
  • Hydraulic MPA pressure gauge mounted on right side of support frame with quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness, incorporating with hydraulic overload protection.
  • Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.
  • The vertical supporting slides are treated to provide greater ware resistance and increased accuracy.
  • Reinforced side frames providing addition support strength to machine throat.

Includes

  • Swivel pendant control unit operated by NC-89 Go-To controller “X” & “Y” Axis
  • Sliding front sheet support arms
  • Emergency stop buttons conveniently located on control panel and foot control
  • Mobile dual operation foot control
  • Segmented 86° offset top punch
  • Solid one piece four way multi vee (V) die block
  • Quick action top punch tool holder system with wedge type adjustment
  • Powered operated leadscrew backgauge with 600mm travel, operated by NC-89 Go-To controller
  • Oil tank level indicator
  • Metal constructed safety guarding surrounding machine with clear side viewing panels
  • Integrated hydraulic system allowing rapid approach switching automatically to slow bend

parameters:

Model

Nominal

Pressure

(KN)

Length

Of Table

(mm)

Distance

Betwween

Housings

(mm)

Throat

Depth

(mm)

Stroke

(MM)

Open

Height

(mm)

Main

Motor

(KW)

Gross Weight

(ton)

 Dimensions

(LxWxH)

(mm)
63/2500 630 2500 2000 320 150 380 5.5 4.5 2825x1650x2350
63/3200 630 3200 2700 320 150 380 5.5 5.5 3800x1650x2450
100/3200 1000 3200 2700 400 180 440 7.5 7.5 3810x1750x2530
125/3200 1250 3200 2700 400 180 440 7.5 8.5 3820x1800x2530
125/4000 1250 4000 3200 400 180 440 7.5 9.8 4600x1800x2580
160/3200 1600 3200 2700 400 180 450 11 10.8 3830x1870x2560
160/4000 1600 4000 3200 400 180 450 11 12.8 4610x1920x2700
200/3200 2000 3200 2700 400 180 450 11 12.5 3900x1920x2560
200/4000 2000 4000 3200 400 180 450 11 13.8 4620x1950x2700
200/6000 2000 6000 4800 400 180 480 11 22 6080x1950x2900
250/3200 2500 3200 2700 400 200 480 15 16.5 3900x2150x2950
250/4000 2500 4000 3200 400 200 480 15 17.5 4080x2150x3000
250/5000 2500 5000 4000 400 250 560 15 17.5 5080x2200x3200
250/6000 2500 6000 4800 400 250 560 15 21 6080x2200x3400
300/3200 3000 3200 2700 400 250 560 22 17.5 3280x2180x3100
300/4000 3000 4000 3200 400 250 560 22 20.5 4080x2250x3200
300/5000 3000 5000 4000 400 250 560 22 22 5100x2300x3300
300/6000 3000 6000 4800 400 250 560 22 25 6150x2300x3500
400/4000 4000 4000 3200 400 320 630 30 26 4100x2400x4000
400/5000 4000 5000 4000 500 320 630 30 29 5200x2600x4150
400/6000 4000 6000 4800 500 320 630 30 38.5 6200x2650x4300
500/4000 5000 4000 3200 600 320 630 37 41 4200x2800x4100
500/5000 5000 5000 4000 600 320 630 37 46.5 5200x2800x4200
500/6000 5000 6000 4800 600 320 630 37 52 6200x2800x5200
600/5000 6000 5000 4000 600 320 630 45 57 5200x3000x5300
600/6000 6000 6000 4800 600 320 630 45 59.5 6200x3000x5600
800/5000 6000 5000 4000 700 350 800 55 76.8 5200x3500x5600
800/6000 5000 6000 4800 700 350 800 55 87.5 6200x3500x5800
1000/6000 10000 6000 4800 800 350 800 55 108 6200x4100x6900



Why choose us?

 1.Our advantage

Shen Chong (SC) is a mature brand in CHINA, after more than 20 years’ research, our design from technology, structure, security and precision has enhanced greatly. And we also obtained the CE and more strict standard certification. Our machines distribute worldwide about 20 countries which penetrate into more metal plate industries.



2.Certification

WC67Y-125/6000MM Hydraulic press brake machine for iron palte



3.Exhibition

we attend exhibitions to other countries every year. Like  Australian, India, Mexico,Russia,Pakistan,etc.

 4.Customer visit

Up to now, we have many clients to visit our factory, they are  end-user and agency. They are from  Australia, India,  Chile,  Saudi Arabia,etc.

WC67Y-125/6000MM Hydraulic press brake machine for iron palte



Company Information



      Sheng Chong Machine is a high-tech enterprise integrated by R&D, production and after-sale service in CNC hydraulic forging Machine.

      Our factory occupies more than 30,000 m2, it has excellent and professional technical team, 10 R&D personnel with strong developing capability; around 200 workers producing more than 800 sets machines each year, and professional after-sales team to solve various problems which the customer may encounter in using the machine. With new design, fine technology, we get a good evaluation and brand effect in Beijing Machine tool Show, Italy Milan machine tool exhibition, Australia machinery exhibition etc.

     Our main products contain QC11K series CNC guillotine cutting machine, QC11Y series hydraulic shearing machine, QC11YK series fast hydraulic shearing machine for metal plate, QC12K series NC hydraulic swing beam shear machine,QC12Y series hydraulic swing beam cutting machine; WC67Y series hydraulic press brake, WC67K series CNC hydraulic bending machine,WE67K series CNC electro-hydraulic synchronization press brake; SW11C series 3 roller rolling machine, W12NC series 4 rollers rolling machine for metal plate; Laser cutting machine, flame & plasma cutting machine; Automatic slitting machine line; Bending mould for press brake, blade for shearing machine etc.

     So far, our company has been serving more than thousands of customers in light industry, aviation, metallurgy, instrumentation, electrical, stainless steel products, construction and decoration and other industries.

     With high quality hydraulic machine, competitive price and excellent service, we have gained great reputation from more and more domestic and foreign customers!

 WC67Y-125/6000MM Hydraulic press brake machine for iron palte



FAQ

1. Are you a trading company or factory?
  --- We are factory occupying more than 30,000 m2,  with excellent and professional technical team, 10 R&D personnel, professional after-sales team, and around 200 workers producing more than 800sets machines each year.

2. Does your company supply and build the machines to suit customer's needs and specifications?
  --- Yes, we can custom-made the machine according to your requirements.

3. What is your advantages over your competitors' machine?
  --- Our machines can be equipped with high configuration, and main components are from famous brands. We have strict quality control system, process technology system, technology innovate system.

4. Does the machine come with a guarantee?
  --- We offer one year of warranty, during this time the technical guidance and accessories are provided for free.

5. Can I go to visit your factory?
  --- Welcome to visit our factory to know our processing and technology power. And you will see different sample machine at our workshop.

6. How to get quicker quotation?
  --- When you send us inquiry, please offer your requirement information:
• What kind of metal plate and the thickness?
• How about your configuration requirement?
• You also send us your bend products image, our engineer can design for you.


These information is helpful for us to choose suitable equipment solution and price quickly.



More choice

 More kinds machines you can have a widely choice:

Number  Model Forging machinery
1 QC11Y hydraulic shearing machine
2 QC11K cnc shearing machine
3 QC11YK rapid hydraulic shearing machine
4 WC67Y hydraulic bending machine
5 WC67K cnc bending machine
6 WE67K electro-hydraulic synchronous CNC bending machine
7 WG67K high speed bending machine
8 SW11SNC rolling machine series
