HSP-588 Travel Head Cutting Machine

HSP-588  Travel head cutting machine

Detailed Product Description

cutting machine

The Hydraulic Pressure Travel Head automatic round cutting machine (same as atom) is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fiber, non-woven and other materials with shaped blade.

1. Adopting the structure of gantry framework, so the machine has high intensity and keep its shape.

2. The punch head can automatically move transversely, so visual field is perfect and the operation is safe.

3. Return stroke of the platen can be set arbitrarily to reduce idle stroke and improve efficiency.

4. Using differential oil way, cut is rapid and easy.

Main Features:

• Pushbutton controls (time interlock synchronization during cutting phase) to ensure positive safety for the operator
• Really exceptional trolley displacement speed
• High power continuity
• Low energy consumption
• High reliability, no primary maintenance required
• On Demand

  	HYL4-250	HYL4-250A	HYL4-350	HYL4-350A	HYL4-500	HYL4-500A
  Serviceable breadth	1600 mm	1800 mm	1800 mm	2000 mm	1800 mm	2000 mm
  Travel head	500x500 mm	650x650 mm	650x650 mm	760 x 760 mm	650x650 mm	760 x 760 mm
  Maximum cutting power	25tons	25tons	35tons	35tons	50tons	50tons
  Stoke adjustable from-to	5-150 mm	5-150 mm	5-150 mm	5-150 mm	5-150 mm	5-150 mm
  Pump motor	2.2KW	2.2KW	3.0KW	3.0KW	4.0KW	4.0KW
  Travel head speed	1.07 m/sec	1.07 m/sec	1.07 m/sec	1.07 m/sec	1.07 m/sec	1.07 m/sec
  Dimensions	2200 x720x2200 mm	2400x720x205 0mm	2500x900x2100 mm	2700x900x2200 mm	2500x900x2200 mm	2700x900x2200 mm
  Net weight, with oil	1600 Kg	2100Kg	2600kg	3000 Kg	3800kg	5000kg



Feed Systems Available: Roll Feed Systems

                                               Clamp Feed Systems

Factory direct sale; Guarantee Period one year

Note: we can produce different types, tons and cutting area of machine according to your demand.

Production Picture

Process Picture

Price term:  FOB Shanghai                  Payment term:  T/T

Supply Ability: 100 sets/month            MOQ:  1 set

Sample delivery time:  2-3 days

Delivery Time:  within 20 days after samples confirmed

 Artwork: plane cutting machine, travel head cutting machine, four-column cutting machine and so on .

FAQ:

1.Q:Are you a factory or trading company?
A: Yes,we are a factory. you are most welcomed to visit us .

2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Xinghua City, Jiangsu Province, China, about 4 hours from Shanghai.All our clients, from home or abroad, are warmly welcome to visit us!

3.Q:Have you ever attended any exhibitions ?
A: Sure.

Sample: 2012 Guangzhou exhubition

4.Q:What is the material of your products?

A: The material is mainly steel. We can also choose material as customers’ requirements.

5.What is the artwork of your products,can print our logo?

A: Yes,we can provide your logo.

6.Q:Can I get some samples?
A: We are honored to offer you samples in advance.

7.Q:How does your factory do regarding quality control?
A: Quality is priority. Huaying people always attach great importance to quality controlling from the very beginning to the very end.  Our factory has gained ISO authentication.

Welcome to contact us for more details ,most competitive price for you!
