Product Name: tea bag packaging machine(coffee bag,tea bag,juice bag,powder bag)
Model: JW-A10
1. Application
* It is suitable for weighing small weight granules such as seeds, tea, coffee,beans etc.
2. Features
* Adop high accurate loadcell of famous brand.
* 0.3L hopper, Low vibrating design, good performace.
* Arc-shaped machine frame and new machine body cover, improves stability and apperance.
* Integral machine frame with middle standing increases the stability of machine frame and hoppers.
* Integrate waterproof cover and new waterproof shell increase waterproof performance.
3. Mechanical Character
* Added the function of detecting automaticaly for hopper's motor position helps to avoid hoppers'
anomalous closing when the machine starts to zero.
4. Technical Specification
| Model | JW-A10 |
| Identify Code | AS10-1-2 |
| Single Weighing Range | 1-60g |
| Accuracy | X(0.5) |
| Max Speed | 65 P/M |
| Hopper Volume | 0.3 L |
| Control Panel | 7.0'' Touch Screen |
| Options | Dimple Plate /Timing Hopper/Printer/Reject Device |
| Driving System | Step Motor |
| Power Requirement | 220V/900W/50/60HZ/8A |
| Packing Dimension(mm) | 1200(L)X980(W)X980(H) |
| Gross Weight | 180kg |
